Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Ultimate
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revolution iLink 29 SL , Newly developed corratec Revolution iLink fullsuspension frame, ultra lightweight VPP frame, with sensible VPP rear suspension system for best traction in any terrain. Material: Carbon, Weight among 2.000 grams, Unique Inside Link Technology
Suspension Fork
Rockshox SID SL Ultimate 29" Boost , Suspension travel: 100 mm
Rear Shock
Rockshox SID Luxe Ultimate
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS 12S
Shift Levers
SRAM AXS Eagle
Cassette
SRAM XG1299 Eagle , Number of pinions; Ratio: 12S; 10 12 14 16 18 21 24 28 32 36 42 52
Crank
SRAM XX1 Eagle DUB , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
Mavic Crossmax , Rim height: 30 mm, Rim outer diameter: 29.00 zoll, Width outside: 25 mm, Number of spokes: 24, Type of tires: Tubeless Ready, Material: Alloy
Tires
Schwalbe Racing Ray front , Inside diameter: 29.00 zoll, Schwalbe Racing Ralph rear , Inside diameter: 29.00 zoll
Brakes
Brakes
SRAM Level Ultimate , Size brake disc: 180 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX SLR Carbon , Material: Carbon
Seat
Saddle
Selle Italia Superflow Carbon
Seatpost
Rockshox Reverb AXS
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 48cm | 52cm |
|---|---|---|---|
| Stack Reach Ratio | 1.357 mm | 1.299 mm | 1.291 mm |
| Stack | 604 mm | 609 mm | 625 mm |
| Reach | 445 mm | 469 mm | 484 mm |
| Top Tube Length | 586 mm | 613 mm | 629 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 101 mm | 108 mm | 124 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1137 mm | 1164 mm | 1182 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
Revolution iLink SL Factory belongs to the Corratec Revolution model. Corratec released 9 bikes variations of this model so far. You can easily view all of the Corratec Revolution bikes models from 2023, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Revolution iLink SL Factory components
Fork
The fork installed on this bike is the RockShox SID SL Ultimate model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Corratec Revolution iLink SL Factory 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Corratec Revolution iLink SL Factory comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
