Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM
-
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec X Vert Elite , Material: Alloy
Suspension Fork
SR Suntour XCM DS 29" , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
L-Twoo A12 X
Shift Levers
L-Twoo AX 11S
Cassette
L-Twoo CS A11 , Number of pinions; Ratio: 11s; 11 13 15 17 19 21 24 28 32 37 42
Crank
Lasco Electric Black , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
ZZYZX Cross Attack 29 Boost , Rim outer diameter: 29.00 zoll
Tires
Innova IB-3014N , Inside diameter: 29.00 zoll
Brakes
Brakes
Clarks Clout , Size brake disc: 180 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem , Material: Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
Selle Italia X-Base
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.456 mm | 1.398 mm | 1.354 mm |
| Stack | 611 mm | 619 mm | 629 mm | 639 mm |
| Reach | 405 mm | 425 mm | 450 mm | 472 mm |
| Top Tube Length | 574 mm | 596 mm | 624 mm | 649 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 91 mm | 99 mm | 110 mm | 121 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1119 mm | 1142 mm | 1171 mm | 1197 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
X Vert 29 Elite is part of the Corratec X model. Corratec launched 15 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
X Vert 29 Elite components
Fork
The Suntour XCM is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The X Vert 29 Elite 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The X Vert 29 Elite has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
