Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM
-
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec X Vert Elite , Material: Alloy
Suspension Fork
SR Suntour XCM DS 29" , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
L-Twoo A11-X 11S
Shift Levers
L-Twoo AX 11S
Cassette
L-Twoo CS A11 , Number of pinions; Ratio: 11s; 11 13 15 17 19 21 24 28 32 37 42
Crank
Lasco Electric Black , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
ZZYZX Cross Attack 29 Boost front , Rim outer diameter: 29.00 zoll, ZZYZX Cross Attack 29 Boost rear , Rim outer diameter: 29.00 zoll
Tires
Innova IB-3014N front , Inside diameter: 29.00 zoll, Innova IB-3014N rear , Inside diameter: 29.00 zoll
Brakes
Brakes
Clarks Clout front , Size brake disc: 180 mm, Clarks Clout rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX SL Alloy Stem , Material: Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
Corratec Sport
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.456 mm | 1.398 mm | 1.354 mm |
| Stack | 611 mm | 619 mm | 629 mm | 639 mm |
| Reach | 405 mm | 425 mm | 450 mm | 472 mm |
| Top Tube Length | 574 mm | 596 mm | 624 mm | 649 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 91 mm | 99 mm | 110 mm | 121 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1119 mm | 1142 mm | 1171 mm | 1197 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
X Vert Elite completes the Corratec X model. Corratec launched 26 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
X Vert Elite components
Fork
The X Vert Elite comes factory-installed with the Suntour XCM fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Corratec X Vert Elite 2024, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The X Vert Elite comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
