Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 125mm -
Fork Cane Creek HELM
-
Groupset GX Eagle -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Suspension Fork
Cane Creek HELM
Rear Shock
Cane Creek DB Air IL, Climb Switch, 190mm length, 45mm stroke (125mm travel), 50mm stroke (135mm travel)
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle, 12-speed, 10-50 tooth
Crank
SRAM GX Eagle DUB
Bottom Bracket
SRAM DUB, 73mm BSA threaded
Chain
SRAM GX Eagle, 12-speed
Chain Guide
OneUp Top Guide
Pedals
N/A
Wheels
Front Hub
Hope Fortus 26 wheelset, 6-bolt rotor mounts, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Hope Fortus 26 wheelset, 6-bolt rotor mounts, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Hope Fortus 26 wheelset
Spokes
Hope Fortus 26 wheelset
Tires
Front: WTB Vigilante, tubeless kit, 27.5" x 2.5", Rear: WTB Trail Boss, tubeless kit, 27.5" x 2.4"
Brakes
Brakes
Shimano Deore XT M8100, Shimano 180mm 6-bolt rotors
Brake Levers
Shimano Deore XT M8100
Cockpit
Stem
Cotic SHORTERSTEM, 35mm
Handlebar
Cotic Calver, 780mm width, 25mm rise, 5° upsweep, 9° backsweep
Grips
Cotic, lock-on
Headset
Hope 2H, ZS44/EC44
Seat
Saddle
Cotic
Seatpost
X-Fusion Manic Stealth dropper, 125mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.26 mm | 1.22 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm |
| Front Center | 746 mm | 772 mm | 800 mm |
| Rake | 47 mm | 46 mm | 47 mm |
| Trail | 107 mm | 108 mm | 107 mm |
| Stack | 586.8 mm | 595.8 mm | 604.8 mm |
| Reach | 451 mm | 474 mm | 497 mm |
| Top Tube Length | 611 mm | 636 mm | 663 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1189 mm | 1215 mm | 1243 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Flare Gold GX Eagle completes the Cotic Flare model. There are 5 bikes that carry this model name. Take a sneak peek at all Cotic Flare bikes models from 2020, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Flare Gold GX Eagle components
Fork
The fork installed on this bike is the Cane Creek HELM model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Cotic Flare Gold GX Eagle bike has the Cane Creek DB Air IL model installed, and has a travel of 125mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the Flare Gold GX Eagle model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Flare Gold GX Eagle has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Cotic Flare Gold GX Eagle includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
