Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 130mm -
Travel Rear 125mm -
Fork Cane Creek HELM
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Suspension Fork
Cane Creek Helm
Rear Shock
Cane Creek DB Air IL, Climb Switch, 210mm x 50mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8000, 11-speed
Front Derailleur
None
Shift Levers
Shimano Deore XT M8000, 11-speed
Cassette
Shimano Deore XT M8000, 11-speed, 11-46 tooth
Crank
Shimano Deore XT M8000
Bottom Bracket
Shimano Deore XT MT800, 73mm English/BSA threaded
Chain
Shimano Deore XT M8000, 11-speed
Chain Guide
Cotic integrated upper slider
Pedals
None
Wheels
Front Hub
Hunt Trail Wide V2 wheelset, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Hunt Trail Wide V2 wheelset, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Hunt Trail Wide V2 wheelset
Spokes
Hunt Trail Wide V2 wheelset
Tires
Wolfpack Trail/Cross, 29" x 2.4"
Brakes
Brakes
Shimano Deore M6100, 2-piston, Shimano 180mm 6-bolt rotors
Brake Levers
Shimano Deore M6100
Cockpit
Stem
Cotic SHORTERSTEM, 35mm
Handlebar
Cotic Calver, 780mm width, 25mm rise, 5° upsweep, 9° backsweep
Grips
Cotic, lock-on
Headset
Hope Tech 2H, ZS44/EC44
Seat
Saddle
Cotic
Seatpost
BikeYoke Devine dropper, 125mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.32 mm | 1.28 mm | 1.23 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 755 mm | 783 mm | 809 mm | 839 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 616.2 mm | 625.3 mm | 634.4 mm | 643.6 mm |
| Reach | 451 mm | 474.5 mm | 497 mm | 522 mm |
| Top Tube Length | 603 mm | 630 mm | 655 mm | 683 mm |
| Seat Tube Angle | 75.1 ° | 75.1 ° | 75.1 ° | 75.1 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm | 495 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1207 mm | 1235 mm | 1262 mm | 1291 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
FlareMAX Gold XT completes the Cotic Flaremax model. Cotic launched 47 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Cotic FlareMAX Bronze Microshift Advent X 1×10 2022 is the most economical model, with a starting price of 3830$. Cotic FlareMAX Mullet Gold SRAM GX AXS 2022 on the other hand costs 6093$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
FlareMAX Gold XT components
Fork
The fork installed on this bike is the Cane Creek HELM model. The travel on this model is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the Cane Creek DB Air IL model, with a travel of 125mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on FlareMAX Gold XT are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The FlareMAX Gold XT has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Cotic FlareMAX Gold XT comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
