Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 130mm -
Travel Rear 125mm -
Fork X Fusion
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Steel
Suspension Fork
X-Fusion McQueen RL2
Rear Shock
X-Fusion O2 RCX, 200mm x 50mm
Drivetrain
Rear Derailleur
Shimano XT M8000, 11-speed
Front Derailleur
N/A
Shift Levers
Shimano XT M8000, 11-speed
Cassette
Shimano SLX, 11-speed, 11-46 tooth
Crank
Race Face Turbine Cinch, 175mm length
Bottom Bracket
Race Face, 30mm spindle, 73mm BSA threaded
Chain
Shimano XT M8000, 11-speed
Chain Guide
OneUp Top Guide
Pedals
N/A
Wheels
Front Hub
Shimano Deore, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Shimano Deore, 110x15mm Boost front, 148x12mm Boost rear
Rims
WTB ST i29
Tires
Continental Trail King, 29" x 2.2"
Brakes
Brakes
Shimano Deore, Shimano 180mm rotors
Brake Levers
Shimano Deore
Cockpit
Stem
Cotic SHORTERSTEM, 35mm
Handlebar
Cotic Calver, 780mm width, 25mm rise, 5° upsweep, 9° backsweep
Grips
Cotic, lock-on
Headset
Cane Creek 40 Series, ZS44/EC44
Seat
Saddle
Cotic
Seatpost
X-Fusion Manic Stealth dropper, 125mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.32 mm | 1.28 mm | 1.23 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 755 mm | 783 mm | 809 mm | 839 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 122 mm | 122 mm | 122 mm | 122 mm |
| Stack | 616.2 mm | 625.3 mm | 634.4 mm | 643.6 mm |
| Reach | 451 mm | 474.5 mm | 497 mm | 522 mm |
| Top Tube Length | 603 mm | 630 mm | 655 mm | 683 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm | 495 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1207 mm | 1235 mm | 1262 mm | 1291 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
FlareMAX Silver 1×11 is part of the Cotic Flaremax model. 47 bikes variations carry this model name so far. Take a sneak peek at all Cotic Flaremax bikes models from 2020, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This bike has the X Fusion fork installed. The fork’s travel is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Cotic FlareMAX Silver 1×11 bike has the X-Fusion O2 RCX model installed, and has a travel of 125mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the FlareMAX Silver 1×11 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The FlareMAX Silver 1×11 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the FlareMAX Silver 1×11. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
