Cotic FlareMAX4 Trail / Platinum XTR eeWing 2023
2023 Mountain
Estimate price |
8,898$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 130mm -
Travel Rear 125mm -
Fork Cane Creek HELM
-
Groupset XTR, Cane Creek -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 171cm
MD
168cm - 180cm
LG
178cm - 188cm
XL
186cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Cane Creek HELM29 - 130mm
Rear Shock
Cane Creek DB Air IL Climb Switch 210x50
Drivetrain
Rear Derailleur
XTR M9100 1x12 Drivetrain
Cassette
Garbaruk 12spd 10-52 Cassette
Crank
Cane Creek eeWings ti chainset 170mm + Garbaruk Shimano Chainring
Bottom Bracket
RaceFace 30mm BB
Wheels
Rims
Hope Fortus30 Single Cavity 29 Microspline (black Pro5 hubs)
Tires
WTB 29 Verdict 2.5 / Trail Boss 2.4 Light Slashguard with tubeless kit
Brakes
Brakes
Hope standard (non-floating) rotors 203/180 6bolt
Cockpit
Stem
Hope Gravity 35mm Stem 31.8mm Clamp (black)
Handlebar
Hope Carbon Bar 800 x 20mm Rise 31.8 Clamp
Headset
Hope 2H for tapered steerer (black)
Seat
Seatpost
BikeYoke Devine Seatpost 160mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.32 mm | 1.28 mm | 1.23 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 755 mm | 783 mm | 809 mm | 838 mm |
| Rake | 44 mm | 44 mm | 44 mm | 43 mm |
| Trail | 122 mm | 122 mm | 122 mm | 123 mm |
| Stack | 616 mm | 625 mm | 634 mm | 644 mm |
| Reach | 451 mm | 475 mm | 497 mm | 522 mm |
| Top Tube Length | 603 mm | 630 mm | 655 mm | 683 mm |
| Seat Tube Angle | 75.4 ° | 75.4 ° | 75.4 ° | 75.4 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm | 495 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1208 mm | 1236 mm | 1262 mm | 1291 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 188 cm | 195 cm |
Model Overview
FlareMAX4 Trail / Platinum XTR eeWing belongs to the Cotic Flaremax4 model. 14 bikes variations carry this model name so far. You can easily view all of the Cotic Flaremax4 bikes models from 2023, here.
Model range prices
Cotic FlareMAX4 Downcountry / Silver SLX 2023 is the cheapest bike model and costs 3709$. Cotic FlareMAX4 Trail / Platinum XTR eeWing 2023 is the most expensive one and costs 8088$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 8088$. Doing a quick comparison, we notice that FlareMAX4 Trail / Platinum XTR eeWing price is 192.83% higher than the average cost of a Trail bike.
FlareMAX4 Trail / Platinum XTR eeWing components
Fork
The fork installed on this bike is the Cane Creek HELM model. The travel on this model is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Cane Creek DB Air IL Climb Switch 210×50, with a travel distance of 125mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the FlareMAX4 Trail / Platinum XTR eeWing model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The FlareMAX4 Trail / Platinum XTR eeWing has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 160 cm – 195 cm (5.25 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Cotic FlareMAX4 Trail / Platinum XTR eeWing comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
