Cotic FlareMAX5 Trail / Platinum XTR eeWing 2023
2023 Mountain
Estimate price |
9,902$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 130mm -
Travel Rear 125mm -
Fork Cane Creek HELM
-
Groupset XTR, Cane Creek -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
C1
162cm - 172cm
C2
170cm - 178cm
C3
176cm - 184cm
C4
182cm - 190cm
C5
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Cane Creek HELM29 - 130mm
Rear Shock
Cane Creek DB Air IL Climb Switch 210x50
Drivetrain
Rear Derailleur
XTR M9100 1x12 Drivetrain
Cassette
Garbaruk 12spd 10-52 Cassette
Crank
Cane Creek eeWings ti chainset 170mm + Garbaruk Shimano Chainring
Bottom Bracket
RaceFace 30mm BB
Wheels
Rims
Hope Fortus30 Single Cavity 29 Microspline (black Pro5 hubs)
Tires
WTB 29 Verdict 2.5 / Trail Boss 2.4 Light Slashguard with tubeless kit
Brakes
Brakes
Hope standard (non-floating) rotors 203/180 6bolt
Cockpit
Stem
Hope Gravity 35mm Stem 31.8mm Clamp (black)
Handlebar
Hope Carbon Bar 800 x 20mm Rise 31.8 Clamp
Headset
Hope 2H for tapered steerer (black)
Seat
Seatpost
BikeYoke Devine Seatpost 160mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | C1 | C2 | C3 | C4 | C5 |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.36 mm | 1.32 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 752 mm | 775 mm | 798 mm | 822 mm | 841 mm |
| Rake | 45 mm | 45 mm | 45 mm | 46 mm | 46 mm |
| Trail | 120 mm | 120 mm | 120 mm | 119 mm | 119 mm |
| Stack | 622 mm | 631 mm | 640 mm | 650 | 650 |
| Reach | 446 mm | 465 mm | 484 mm | 503 mm | 522 mm |
| Top Tube Length | 602 mm | 624 mm | 641 mm | 663 mm | 682 mm |
| Seat Tube Angle | 75.4 ° | 75.4 ° | 75.8 ° | 75.8 ° | 75.8 ° |
| Seat Tube Length | 390 mm | 417 mm | 444 mm | 471 mm | 496 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 130 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1205 mm | 1228 mm | 1251 mm | 1275 mm | 1294 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm | 36 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 170 cm | 176 cm | 182 cm | 184 cm |
| Rider Max Height | 172 cm | 178 cm | 184 cm | 190 cm | 195 cm |
Model Overview
FlareMAX5 Trail / Platinum XTR eeWing is a Cotic Flaremax5 model. 15 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Cotic FlareMAX5 Downcountry / Silver SLX 2023 has a starting price of 4621$. Cotic FlareMAX5 Trail / Platinum XTR eeWing 2023 on the other hand is the most expensive at 9000$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Cotic FlareMAX5 Trail / Platinum XTR eeWing price was 9000$. Comparing the average cost of a Trail bike to this one, you will see that FlareMAX5 Trail / Platinum XTR eeWing price is 225.85% higher.
FlareMAX5 Trail / Platinum XTR eeWing components
Fork
This bike has the Cane Creek HELM fork installed. The fork’s travel is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The FlareMAX5 Trail / Platinum XTR eeWing has a rear shock with a travel of 125mm. The model Cane Creek DB Air IL Climb Switch 210×50 is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Cotic FlareMAX5 Trail / Platinum XTR eeWing 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Cotic FlareMAX5 Trail / Platinum XTR eeWing has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 162 cm – 195 cm (5.31 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Cotic FlareMAX5 Trail / Platinum XTR eeWing includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
