Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork X Fusion
-
Groupset XT, Race Face -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
X-Fusion McQueen HLR, Boost 110x15mm thru-axle, tapered steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore XT M8000, 11-speed
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8000, 11-speed
Cassette
Shimano Deore XT M8000, 11-46 tooth, 11-speed
Crank
Race Face Turbine Cinch, 175mm length, direct mount
Bottom Bracket
Threaded BSA, 73mm
Chain
Shimano Deore XT M8000, 11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Hope Tech
Rear Hub
Hope Tech
Rims
Hope Tech XC
Tires
Front: WTB Vigilante, TCS Light Fast Rolling, tubeless, 29" x 2.3", Rear: WTB Trail Boss, Tough Fast Rolling, tubeless, 29" x 2.25"
Brakes
Brakes
Deore XT M8000, 180mm rotors
Brake Levers
Deore XT M8000
Cockpit
Stem
Cotic (35mm or 45mm)
Handlebar
Cotic Calver, 780mm width, 25mm rise
Headset
Hope
Seat
Saddle
Cotic Cromo Rail
Seatpost
X-Fusion Manic dropper, 125mm (SM, MD), 150mm (LG, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.29 mm | 1.25 mm | 1.2 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 734 mm | 757 mm | 783 mm | 815 mm |
| Rake | 46 mm | 46 mm | 45 mm | 46 mm |
| Trail | 116 mm | 116 mm | 117 mm | 116 mm |
| Stack | 607.3 mm | 607.3 mm | 616.4 mm | 625.6 mm |
| Reach | 447.6 mm | 470.3 mm | 493 mm | 520 mm |
| Top Tube Length | 619.8 mm | 642.8 mm | 667.6 mm | 697.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1178 mm | 1201 mm | 1227 mm | 1259 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SolarisMAX Gold 29 completes the Cotic Solarismax model. 22 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
SolarisMAX Gold 29 components
Fork
Cotic SolarisMAX Gold 29 2018 bike is equipped with the X Fusion fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The SolarisMAX Gold 29 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The SolarisMAX Gold 29 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
SolarisMAX Gold 29 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the SolarisMAX Gold 29. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
