Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork Cane Creek HELM
-
Groupset XTR, Race Face -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
Cane Creek Helm 29, Boost 110x15mm thru-axle, tapered steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XTR M9000, 11-speed
Front Derailleur
N/A
Shift Levers
Shimano XTR M9000, 11-speed
Cassette
Hope super light, 10-48 tooth, 11-speed
Crank
Race Face Next R Cinch Carbon, 175mm length, direct mount
Bottom Bracket
Threaded BSA, 73mm
Chain
Shimano XTR M9000, 11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Hope Tech
Rear Hub
Hope Tech
Rims
Hope Tech XC
Tires
Front: WTB Vigilante, TCS Light Fast Rolling, tubeless, 29" x 2.3", Rear: WTB Trail Boss, Light Fast Rolling, tubeless, 29" x 2.25"
Brakes
Brakes
Hope Tech X2, 180mm floating Hope rotors
Brake Levers
Hope Tech X2
Cockpit
Stem
Cotic Shortstem, 35mm length
Handlebar
Burgtec Ride Wide Carbon
Headset
Hope
Seat
Saddle
Cotic Cromo Rail
Seatpost
X-Fusion Manic dropper, 125mm (SM, MD), 150mm (LG, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.29 mm | 1.25 mm | 1.2 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 734 mm | 757 mm | 783 mm | 815 mm |
| Rake | 46 mm | 46 mm | 45 mm | 46 mm |
| Trail | 116 mm | 116 mm | 117 mm | 116 mm |
| Stack | 607.3 mm | 607.3 mm | 616.4 mm | 625.6 mm |
| Reach | 447.6 mm | 470.3 mm | 493 mm | 520 mm |
| Top Tube Length | 619.8 mm | 642.8 mm | 667.6 mm | 697.5 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1178 mm | 1201 mm | 1227 mm | 1259 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SolarisMAX Platinum 29 belongs to the Cotic Solarismax model. Cotic released 22 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
SolarisMAX Platinum 29 components
Fork
This bike has the Cane Creek HELM fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on SolarisMAX Platinum 29 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The SolarisMAX Platinum 29 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
