Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork Suntour XCE
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
155cm - 175cm
LG
170cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, S (15"), M (17"), L (19")
Suspension Fork
Suntour XCE28, 80mm, 29"
Drivetrain
Rear Derailleur
Shimano RD-TX800
Shift Levers
Shimano STEF5002/7 sp.
Crank
Shimano FC-TY301, 42-34-24T, 170mm
Chain
KMC Z50/114L
Pedals
SP 510
Wheels
Rear Hub
Matrix alloy 32H QR black
Rims
CTM ZX-lite, 622x19 BA, GBS, 32H
Tires
Freedom Transition 29x2.25"
Brakes
Brakes
Alhonga V-brake
Cockpit
Stem
Zoom C-41 60/25.4 mm
Handlebar
Zoom MTB-153, 620/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM Elite
Seatpost
Zoom C208, 300/31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Front Center | 655 mm | 675 mm | 695 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 578 mm | 598 mm | 618 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1099 mm | 1109 mm | 1129 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 155 cm | 170 cm |
| Rider Max Height | 170 cm | 175 cm | 190 cm |
About this model
CHARISMA 1.0 is a Ctm Charisma model. CTM released 12 bikes variations of this model so far. Take a sneak peek at all Ctm Charisma bikes models from 2022, by clicking here.
Model range prices
CTM CHARISMA 1.0 2022 is the most economical model, with a starting price of 445$. CTM CHARISMA 6.0 2022 on the other hand costs 997$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When CTM released this model in 2022, its price was 445$. Comparing this to the average Crosscountry bike price, we see that the price is 328.09% smaller.
CHARISMA 1.0 components
Fork
This bike has the Suntour XCE fork installed. The fork’s travel is 80mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the CHARISMA 1.0 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
CTM CHARISMA 1.0 bike has 3 sizes, in the range of 158 cm – 190 cm (5.18 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
