Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset SLX -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL, Solo Air spring, 47mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX M7000, 11-speed, GS cage
Front Derailleur
Shimano SLX M7020
Shift Levers
Shimano SLX M7000, 2x11
Cassette
Shimano SLX M7000, 11-speed, 11-40 tooth
Crank
Shimano SLX M7000, 175mm length
Bottom Bracket
Shimano BB52B, BSA threaded
Chain
KMC X11, 11-speed, 112 links
Chain Guide
N/A
Pedals
VP 519A platform
Wheels
Front Hub
Shimano MT400, 32 hole, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Shimano MT400, 32 hole, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
WTB ST i25 TCS, 32 hole
Tires
WTB Ranger, TCS, Light/Fast Rolling, 29" x 2.25"
Brakes
Brakes
Shimano MT400, 2-piston, Shimano RT54 rotors
Brake Levers
Shimano MT400
Cockpit
Stem
CTM AS 90ex, 31.8mm bar clamp
Handlebar
CTM, 31.8mm clamp diameter, 760mm width
Headset
FSA Orbit 1.5
Seat
Saddle
CTM
Seatpost
CTM SP3D2, 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 700 | 715 mm | 730 mm |
| Top Tube Length | 621 mm | 636 mm | 651 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1140 mm | 1155 mm | 1170 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Rascal 3.0 29″ is a Ctm Rascal model. There are 17 bikes that carry this model name. Take a sneak peek at all Ctm Rascal bikes models from 2020, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly heavier than average, Rascal 3.0 29″ has a weight of 12.9 kg (28.44 lbs). In short, the average Crosscountry bike weight is 4.03% lower than this one.
Rascal 3.0 29″ components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, CTM Rascal 3.0 29″ 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. CTM Rascal 3.0 29″ has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Rascal 3.0 29″ comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
