Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon Gold, DebonAir spring, remote lockout, 47mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
None
Shift Levers
Shimano SLX M7100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Crank
Shimano SLX M7100, 175mm length
Bottom Bracket
Shimano MT800B, BSA threaded
Chain
Shimano Deore M6100, 12-speed
Chain Guide
None
Pedals
VPE 461
Wheels
Front Hub
Shimano, MT400 110x15mm Boost front, MT410 148x12mm Boost rear with MICRO SPINE driver
Rear Hub
Shimano, MT400 110x15mm Boost front, MT410 148x12mm Boost rear with MICRO SPINE driver
Rims
WTB ST i25 TCS, 32 hole
Tires
WTB Ranger, TCS, Light/Fast Rolling, 29" x 2.25"
Brakes
Brakes
Shimano Deore M6100, 2-piston, Shimano RT64 rotors
Brake Levers
Shimano Deore M6100
Cockpit
Stem
CTM ASM02, 35mm bar clamp, 90mm length
Handlebar
CTM HB352, 35mm clamp diameter, 760mm width
Headset
FSA Orbit 1.5
Seat
Saddle
CTM Flat
Seatpost
CTM SP3D2, 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 700 | 715 mm | 730 mm |
| Rake | 47 mm | 47 mm | 47 mm |
| Trail | 90 mm | 90 mm | 90 mm |
| Stack | 634 mm | 634 mm | 634 mm |
| Reach | 441 mm | 456 mm | 471 mm |
| Top Tube Length | 621 mm | 636 mm | 651 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1140 mm | 1155 mm | 1170 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Rascal 4.0 29″ is a Ctm Rascal model. CTM released 17 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 12.3 kg (27.12 lbs), the Rascal 4.0 29″ model is slightly lighter than average. In conclusion, the average Crosscountry bike weighs 0.81% more than Rascal 4.0 29″.
Rascal 4.0 29″ components
Fork
The Rascal 4.0 29″ comes factory-installed with the RockShox Recon Gold RL fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Rascal 4.0 29″ bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. CTM Rascal 4.0 29″ is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Rascal 4.0 29″ comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
