Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (16"), L (18"), XL (20")
Suspension Fork
Suntour XCE28, 100mm, 27.5"
Drivetrain
Rear Derailleur
Shimano RD-TY500
Shift Levers
Shimano STEF5002/7 sp.
Crank
Shimano FC-TY301, 42-34-24T, 170mm
Chain
KMC Z50/110L
Pedals
SP 877
Wheels
Rear Hub
Matrix alloy 32H QR black
Rims
CTM ZX-lite, 584x19 BA, GBS, 32H
Tires
Freedom Transition 27.5x2.25"
Brakes
Brakes
Alhonga V-brake
Cockpit
Stem
Zoom C-41 90/25.4 mm
Handlebar
Zoom MTB-153, 640/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
CTM SP 300x27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Front Center | 657 mm | 683 mm | 694 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 591 mm | 616 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1095 mm | 1120 mm | 1131 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
About this model
REIN 1.0 completes the Ctm Rein model. CTM released 6 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
CTM REIN 1.0 2022 is the most affordable bike of this model and has a price of 434$. On the other hand, CTM REIN 3.0 2022, is the most expensive and costs 636$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, CTM REIN 1.0 price was 434$. Comparing this to the average Crosscountry bike price, we see that the price is 338.94% lower.
Overview of components
Fork
This bike has the Suntour XCE fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the REIN 1.0 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. CTM REIN 1.0 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
REIN 1.0 comes in 3 sizes, that range from 160 cm – 205 cm (5.25 ft – 6.73 ft). In conclusion, finding one for you shouldn’t be a problem.
