Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (16"), L (18"), XL (20")
Suspension Fork
Suntour XCE28, 100mm, 27.5"
Drivetrain
Rear Derailleur
Shimano RD-TY500
Shift Levers
Shimano STEF5002/7 sp.
Crank
Shimano FC-TY301, 42-34-24T, 170mm
Chain
KMC Z50/110L
Pedals
SP 877
Wheels
Rear Hub
Matrix alloy 32H QR black
Rims
CTM ZX-lite, 584x19 BA, GBS, 32H
Tires
Freedom Transition 27.5x2.25"
Brakes
Brakes
Alhonga V-brake
Cockpit
Stem
Zoom C-41 90/25.4 mm
Handlebar
Zoom MTB-153, 640/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
CTM SP 300x27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Front Center | 657 mm | 683 mm | 694 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 591 mm | 616 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1095 mm | 1120 mm | 1131 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
Model Overview
REIN 1.0 belongs to the Ctm Rein model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
CTM REIN 1.0 2023 is the most economical model, with a starting price of 477$. CTM REIN 3.0 2023 on the other hand costs 657$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 477$. If we compare this with the average Crosscountry bike cost we notice that the price is 299.37% smaller.
Overview of components
Fork
The fork installed on this bike is the Suntour XCE model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The REIN 1.0 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. CTM REIN 1.0 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
REIN 1.0 comes in 3 sizes, that range from 160 cm – 205 cm (5.25 ft – 6.73 ft). In conclusion, it won’t take much to find one that’s right for you.
