Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Pike Select
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Pike Select RC, Charger damper, 51mm offset
Rear Shock
RockShox Monarch RT3, 200mm x 50mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Crank
Shimano SLX M7100, 175mm length
Bottom Bracket
Shimano MT800B
Chain
Shimano SLX M7100, 12-speed
Chain Guide
Mozartt upper slider
Pedals
HT PA12 platform
Wheels
Front Hub
DT Swiss E1900 wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPINE driver
Rear Hub
DT Swiss E1900 wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPINE driver
Rims
DT Swiss E1900 wheelset
Spokes
DT Swiss E1900 wheelset
Tires
Front: WTB Trail Boss G2, TCS, 29" x 2.4", Rear: WTB Ranger, TCS, 29" x 2.25"
Brakes
Brakes
Shimano SLX M7120, 4-piston, Shimano RT70 rotors
Brake Levers
Shimano SLX M7120
Cockpit
Stem
Race Face Aeffect R, 35mm bar clamp, 50mm length
Handlebar
Race Face Aeffect R, 35mm clamp diameter, 760mm width, 10mm rise
Headset
FSA Orbit 1.5
Seat
Saddle
WTB Volt
Seatpost
KS LEV Integra dropper, Drop: 125mm (MD), 150mm (LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.27 mm | 1.24 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 742 mm | 763 mm | 785 mm |
| Rake | 52 mm | 52 mm | 52 mm |
| Trail | 102 mm | 102 mm | 102 mm |
| Stack | 587 mm | 596 mm | 606 mm |
| Reach | 452 mm | 469 mm | 487 mm |
| Top Tube Length | 608 mm | 628 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1188 mm | 1209 mm | 1231 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Ridge Pro 29″ belongs to the Ctm Ridge model. CTM released 6 bikes variations of this model so far. Take a sneak peek at all Ctm Ridge bikes models from 2020, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Trail bikes average weight
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 14.1 kg (31.09 lbs), the Ridge Pro 29″ model is a bit heavier than average. In conclusion, the average Trail bike weighs 8.63% less than Ridge Pro 29″.
Overview of components
Fork
This bike has the RockShox Pike Select fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Ridge Pro 29″ has a rear shock with a travel of 130mm. The model RockShox Monarch RT3 is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Ridge Pro 29″ bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. CTM Ridge Pro 29″ is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The CTM model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
