Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox 35 Gold RL
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox 35 Gold RL, DebonAir spring, 51mm offset
Rear Shock
RockShox Monarch RT3, 200mm x 51mm
Drivetrain
Rear Derailleur
Shimano SLX M7100, 12-speed
Front Derailleur
None
Shift Levers
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Crank
Shimano Deore M6100, 170mm length
Bottom Bracket
Shimano
Chain
Shimano Deore M6100, 12-speed
Chain Guide
Upper slider
Pedals
HT PA12 platform
Wheels
Front Hub
Front: Shimano MT400, 110x15mm Boost, Rear: Shimano MT410, 148x12mm Boost, MICRO SPLINE driver
Rear Hub
Front: Shimano MT400, 110x15mm Boost, Rear: Shimano MT410, 148x12mm Boost, MICRO SPLINE driver
Rims
WTB ST i29 TCS 2.0, 32 hole
Tires
WTB Trail Boss, TCS, Light, 29" x 2.4"
Brakes
Brakes
Shimano MT420, 4-piston, Shimano RT54 rotors
Brake Levers
Shimano MT420
Cockpit
Stem
CTM ASM04, 45mm length, 35mm bar clamp
Handlebar
CTM HB352, 760mm width, 35mm clamp diameter
Headset
FSA Orbit 1.5
Seat
Saddle
WTB Volt
Seatpost
KS Rage-i dropper, Drop: 125mm (MD), 150mm (LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.27 mm | 1.24 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 742 mm | 763 mm | 785 mm |
| Rake | 52 mm | 52 mm | 52 mm |
| Trail | 102 mm | 102 mm | 102 mm |
| Stack | 587 mm | 596 mm | 606 mm |
| Reach | 452 mm | 469 mm | 487 mm |
| Top Tube Length | 608 mm | 628 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1188 mm | 1209 mm | 1231 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Ridge Xpert 29″ is part of the Ctm Ridge model. There are 6 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 14.6 kg (32.19 lbs), CTM bike is considerably heavier than average. In short, the average Trail bike weight is 12.48% lower than this one.
Ridge Xpert 29″ components
Fork
CTM Ridge Xpert 29″ 2021 bike is equipped with the RockShox 35 Gold RL fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the RockShox Monarch RT3 rear shock model, which has a travel of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, CTM Ridge Xpert 29″ 2021, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
CTM Ridge Xpert 29″ includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
