Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Lyrik Ultimate
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Lyrik Ultimate RCT3, Charger 2 damper, 51mm offset
Rear Shock
RockShox Super Deluxe Select+ RT, 205mm x 65mm
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano Deore XT M8100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Crank
Shimano SLX M7100, 175mm length
Bottom Bracket
Shimano MT800B
Chain
Shimano SLX M7100, 12-speed
Chain Guide
Mozartt upper slider
Pedals
HT PA12 platform
Wheels
Front Hub
DT Swiss E1900 Spline wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPINE driver
Rear Hub
DT Swiss E1900 Spline wheelset, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPINE driver
Rims
DT Swiss E1900 Spline wheelset
Spokes
DT Swiss E1900 Spline wheelset
Tires
Front: WTB Vigilante, TCS, Light/High Grip, 29" x 2.5", Rear: WTB Trail Boss G2, TCS, Light/Fast Rolling, 29" x 2.4"
Brakes
Brakes
Shimano SLX M7120, 4-piston, Shimano RT70 rotors
Brake Levers
Shimano SLX M7120
Cockpit
Stem
Race Face Turbine R, 35mm bar clamp, 40mm length
Handlebar
Race Face Turbine R, 35mm clamp diameter, 800mm width, 20mm rise
Headset
FSA Orbit 1.5
Seat
Saddle
WTB Volt
Seatpost
KS LEV Integra dropper, Drop: 125mm (MD), 150mm (LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm |
| Front Center | 756 mm | 786 mm | 807 mm |
| Rake | 51 mm | 52 mm | 51 mm |
| Trail | 115 mm | 114 mm | 115 mm |
| Stack | 608 mm | 617 mm | 621 mm |
| Reach | 438 mm | 463 mm | 483 mm |
| Top Tube Length | 600 mm | 627 mm | 649 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 420 mm | 445 mm | 465 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 100 mm | 110 mm | 115 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1204 mm | 1234 mm | 1255 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Scroll Pro 29″ belongs to the Ctm Scroll model. 17 bikes variations carry this model name so far. You can easily view all of the Ctm Scroll bikes models from 2020, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Enduro bikes
On a deeper look, we notice that the average weight of an Enduro bike is 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
a bit heavier than average, Scroll Pro 29″ has a weight of 15.1 kg (33.29 lbs). To sum up, it’s 5.82% heavier than the average weight of Enduro bikes.
Scroll Pro 29″ components
Fork
The Scroll Pro 29″ comes factory-installed with the RockShox Lyrik Ultimate fork. This has a travel range of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Select+ RT model, with a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the Scroll Pro 29″ bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. CTM Scroll Pro 29″ has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The CTM model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
