Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork Suntour NEX -
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (17"), L (19"), XL (21")
Suspension Fork
Suntour NEX, HLO 63mm 700C
Drivetrain
Rear Derailleur
Shimano Altus RD-M370
Shift Levers
Shimano STEF5002/8 sp.
Crank
Shimano FC-TY301, 48-38-28T, 175mm
Chain
KMC Z7/114L
Pedals
SP 510
Wheels
Rear Hub
CTM alloy 32H QR black
Rims
CTM ZX-lite, 622x19 BA, GBS, 32H
Tires
Freedom Wedge 28x1.75" reflex line
Brakes
Brakes
Alhonga V-brake
Cockpit
Stem
CTM adjustable, 90/25.4 mm
Handlebar
CTM rise bar, 640/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
CTM SP 602, 350x31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Front Center | 660 mm | 670 mm | 680 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 600 mm | 610 mm | 620 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 140 mm | 140 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1101 mm | 1112 mm | 1121 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
Model Overview
STARK 1.0 TREK belongs to the Ctm Stark model. 16 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
CTM STARK 1.0 2023 is the most economical model, with a starting price of 615$. CTM STARK 4.0 TREK 2023 on the other hand costs 1443$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Touring bikes average price
Our math shows that the average cost of a dependable Touring bike is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 678$. If we compare this with the average Touring bike cost we notice that the price is 48.53% smaller.
Overview of components
Fork
The Suntour NEX is included from the factory. It has a travel distance of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The STARK 1.0 TREK 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The STARK 1.0 TREK comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 3 sizes. They vary from 160 cm – 205 cm (5.25 ft – 6.73 ft). In short, it won’t be difficult to find the right one for you.
