Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork Suntour NEX -
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (17"), L (19"), XL (21")
Suspension Fork
Suntour NEX, HLO DS 700C
Drivetrain
Rear Derailleur
Shimano RD-TX800
Shift Levers
Shimano Altus SL-M310/8sp.
Crank
Shimano FC-TY301, 48-38-28T, 175mm
Chain
KMC Z7/114L
Pedals
SP 877
Wheels
Rear Hub
CTM alloy center-lock 32H QR black
Rims
CTM ZX-lite, 622x19 BA, 32H
Tires
Freedom Wedge 28x1.75" reflex line
Brakes
Brakes
Shimano MT200 / SMRT10S
Cockpit
Stem
CTM adjustable, 90/25.4 mm
Handlebar
Zoom MTB-153, 620/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
Zoom C208, 300/31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
About this model
TRANZ 3.0 completes the Ctm Tranz model. There are 12 bikes that carry this model name. Take a sneak peek at all Ctm Tranz bikes models from 2023, by clicking here.
Model range prices
The most economical model, the CTM TRANZ 1.0 2023 has a starting price of 477$. CTM TRANZ 3.0 TREK 2023 on the other hand is the most expensive at 647$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 583$. In conclusion, this bike price is 3.74% higher than the price of the average Hybrid bike.
TRANZ 3.0 components
Fork
The fork installed on this bike is the Suntour NEX model. The travel on this model is mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the TRANZ 3.0 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The TRANZ 3.0 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
CTM TRANZ 3.0 bike has 3 sizes, in the range of 160 cm – 205 cm (5.25 ft – 6.73 ft). In short, it won’t be difficult to find the right one for you.
