Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" / 29" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Deore, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Lite, AMF, Internal Cable Routing, Easy Mount Kickstand Ready
Suspension Fork
SR Suntour XCM RL Disc, Remote Lockout, 100mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M592, 9-Speed
Front Derailleur
Shimano FD-M4000, Downswing, 31,8
Shift Levers
Shimano SL-M370, Rapidfire-Plus
Cassette
Shimano CS-HG300, 12-36T
Crank
Shimano FC-M3000, 40x30x22T, 175mm
Chain
Shimano CN-HG53
Pedals
CUBE PP MTB
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
CUBE ZX20, 32H, Disc
Tires
Schwalbe Smart Sam, Active, 2.25"
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680mm
Grips
CUBE Performance Grip
Headset
FSA No.10, Semi-Integrated
Seat
Saddle
CUBE Active 1.1
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 17" | 18" | 19" | 20" | 21" | 23" |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.57 mm | 1.61 mm | 1.57 mm | 1.57 mm | 1.56 mm | 1.53 mm | 1.55 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 314 mm | 304 mm | 314 mm | 304 mm | 314 mm | 314 mm |
| Front Center | 608 mm | 631 mm | 647 mm | 644 mm | 662 mm | 666 mm | 683 mm | 693 mm |
| Rake | 43 mm | 43 mm | 51 mm | 44 mm | 51 mm | 44 mm | 51 mm | 51 mm |
| Trail | 90 mm | 90 mm | 86 mm | 83 mm | 82 mm | 83 mm | 82 mm | 82 mm |
| Stack | 599 mm | 599 mm | 624 mm | 622 mm | 635 mm | 641 mm | 645 mm | 659 mm |
| Reach | 358 mm | 381 mm | 387 mm | 396 mm | 404 mm | 411 mm | 421 mm | 426 mm |
| Top Tube Length | 533 mm | 556 mm | 576 mm | 578 mm | 596 mm | 599 mm | 616 mm | 626 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73.5 ° | 73 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 355 mm | 405 mm | 420 mm | 450 mm | 470 mm | 490 mm | 515 mm | 565 mm |
| Head Tube Angle | 69 ° | 69 ° | 69.5 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 105 mm | 110 mm | 125 mm | 120 mm | 145 mm | 130 mm | 145 mm |
| Chainstay Length | 433 mm | 433 mm | 456 mm | 433 mm | 456 mm | 433 mm | 456 mm | 456 mm |
| Wheelbase | 1036 mm | 1059 mm | 1096 mm | 1072 mm | 1111 mm | 1094 mm | 1132 mm | 1142 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 60 mm | 51 mm | 60 mm | 51 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 29" | 27" | 29" | 27" | 29" | 29" |
About this model
AIM SL is a Cube Aim model. 58 bikes variations carry this model name so far. You can easily view all of the Cube Aim bikes models from 2017, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
CUBE AIM SL it’s weighing 14.4 kg (31.75 lbs). At this weight, is much heavier than average. In other words, this model is 16.13% heavier than the average Crosscountry bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The AIM SL 2017 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The AIM SL has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
