Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Deore, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Lite, AMF, Internal Cable Routing, Easy Mount Kickstand Ready
Suspension Fork
SR Suntour XCM ATB Coil, 100mm, Lockout
Drivetrain
Rear Derailleur
Shimano Deore RD-M592, 9-Speed
Front Derailleur
Shimano FD-M4000, Downswing, 31.8mm Clamp
Shift Levers
Shimano SL-M2000, Rapidfire-Plus
Cassette
Shimano CS-HG400, 12-36T
Crank
Shimano FC-MT100, 40x30x22T, 175mm
Chain
Shimano CN-HG53
Pedals
CUBE PP Trekking
Wheels
Front Hub
Shimano DH-3D37, Hub Dynamo, QR
Rear Hub
Shimano FH-TX505, QR, Centerlock
Rims
CUBE ZX20, 32H, Disc
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680 mm
Grips
CUBE Performance Grip
Headset
CUBE No.10 Semi-Integrated
Seat
Saddle
Selle Royal MTB
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 18" |
|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.57 mm | 1.57 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm |
| Front Center | 608 mm | 631 mm | 644 mm |
| Rake | 43 mm | 43 mm | 44 mm |
| Trail | 90 mm | 90 mm | 83 mm |
| Stack | 599 mm | 599 mm | 622 mm |
| Reach | 358 mm | 381 mm | 396 mm |
| Top Tube Length | 533 mm | 556 mm | 578 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 355 mm | 405 mm | 450 mm |
| Head Tube Angle | 69 ° | 69 ° | 70 ° |
| Head Tube Length | 105 mm | 105 mm | 125 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1036 mm | 1059 mm | 1072 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 51 mm |
| Wheels | 27" | 27" | 27" |
Model Overview
AIM SL Allroad 27.5 belongs to the Cube Aim model. 58 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 16.1 kg (35.49 lbs), CUBE bike is much heavier than average. To sum up, it’s 29.84% heavier than the average weight of Crosscountry bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
AIM SL Allroad 27.5 components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on AIM SL Allroad 27.5 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The AIM SL Allroad 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
