Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Factory Float 32
-
Groupset XX1, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C:68 Monocoque Advanced Twin Mold Technology, ARG, ERC, FSP 4-Link, Boost148, AXH
Suspension Fork
Fox 32 Float SC FIT4 Factory, 2-Position Remote Lever, Tapered, 15mm Boost, Kashima Coated, 100mm
Rear Shock
Fox Float DPS Factory Remote, 165x38mm, 2-Position Remote Lever, Kashima Coated
Drivetrain
Rear Derailleur
SRAM XX1, 11-Speed
Shift Levers
SRAM XX1 Trigger
Cassette
SRAM XG-1199, 10-42T
Crank
Race Face Next SL Carbon 34T, 175mm, Oversized Aluminum Axle
Chain
SRAM PC-XX1
Wheels
Rims
Newmen Advanced SL X.22 Carbon, 28/28 Spokes, 15mm / Boost X12, Tubeless Ready
Tires
Schwalbe Rocket Ron, Kevlar, 2.1, LiteSkin
Brakes
Brakes
SRAM Level Ultimate, Hydr. Disc Brake (160/160)
Cockpit
Stem
Newmen Evolution SL 318.2, 31.8mm
Handlebar
Newmen Advanced SL 318.0 Carbon, 740mm
Grips
CUBE SCR
Headset
FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
CUBE SLT Zero Carbon
Seatpost
Newmen Advanced SL Carbon, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 659 mm | 685 mm | 709 mm | 732 mm |
| Rake | 50 mm | 51 mm | 51 mm | 51 mm |
| Trail | 83 mm | 82 mm | 82 mm | 82 mm |
| Stack | 594 mm | 604 mm | 613 mm | 622 mm |
| Reach | 409 mm | 431 mm | 451 mm | 471 mm |
| Top Tube Length | 569 mm | 594 mm | 617 mm | 640 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 97 mm | 107 mm | 117 mm | 127 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1103 mm | 1129 mm | 1153 mm | 1176 mm |
| Bottom Bracket Drop | 42 mm | 42 mm | 42 mm | 42 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
AMS 100 C:68 SLT 29 is a Cube Ams model. CUBE launched 32 bikes of this model so far. Take a sneak peek at all Cube Ams bikes models from 2017, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 8.9 kg (19.62 lbs), CUBE bike is much lighter than average. To sum up, it’s 39.33% lighter than the average weight of Crosscountry bikes.
AMS 100 C:68 SLT 29 components
Fork
The AMS 100 C:68 SLT 29 comes factory-installed with the Fox Factory Float 32 fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the Fox Float DPS Factory Remote model, with a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The AMS 100 C:68 SLT 29 2017 bike is equipped with 29″ carbon wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE AMS 100 C:68 SLT 29 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
