Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GTC Monocoque Twin Mold Technology, Road Comfort Geometry
Suspension Fork
CUBE CSL Race, One Piece 3D Forged Steerer/Crown, Carbon Blades, 1 1/8" - 1 1/4" Tapered
Drivetrain
Rear Derailleur
Shimano 105 RD-5800GS, 11-Speed
Front Derailleur
Shimano 105 FD-5800, 31.8mm Clamp
Shift Levers
Shimano 105 ST-5800
Cassette
Shimano 105 CS-5800, 11-32T
Crank
Shimano 105 FC-5800, 50x34T
Chain
Shimano CN-HG600-11
Wheels
Rims
Mavic Aksium Elite
Tires
Conti Grand Sport Race SL, 25-622
Brakes
Brakes
Shimano 105 BR-5800
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Wing Race Bar Compact
Headset
FSA I-t, Top Integrated 1 1/8", Bottom Integrated 1 1/4"
Seat
Saddle
CUBE RP 1.0
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 56cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.5 mm | 1.54 mm |
| Bottom Bracket Height | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 581 mm | 581 mm | 591 mm | 605 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 66 mm | 61 mm | 58 mm | 54 mm |
| Stack | 521 mm | 534 mm | 557 mm | 587 mm |
| Reach | 361 mm | 365 mm | 372 mm | 381 mm |
| Top Tube Length | 506 mm | 513 mm | 533 mm | 556 mm |
| Seat Tube Angle | 74.6 ° | 74.6 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 70.6 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 152 mm | 182 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 976 mm | 976 mm | 986 mm | 1000 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
AXIAL WLS GTC Pro completes the Cube Axial model. CUBE launched 50 bikes of this model so far. Take a sneak peek at all Cube Axial bikes models from 2017, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Endurance bikes average weight
On a deeper look, we notice that the average weight of an Endurance bike is 8.2 kg (18.08 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 8.4 kg (18.52 lbs), CUBE bike is slightly heavier than average. In conclusion, the average Endurance bike weighs 2.44% less than AXIAL WLS GTC Pro.
AXIAL WLS GTC Pro components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The AXIAL WLS GTC Pro 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The AXIAL WLS GTC Pro has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
