CUBE AXIAL WS Race 2021
2021 Road
Estimate price |
1,662$
Weight | 9.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 T6 Superlite, Double Butted, Smooth Welded, 3D Dropouts, Road Comfort Geometry
Suspension Fork
CUBE CSL Race Disc, One Piece 3D-Forged Steerer/Crown, Carbon Blades, 1 1/8" - 1 1/4" Tapered, Flat Mount, 12x100mm
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000-DGS, 11-Speed
Front Derailleur
Shimano 105 FD-R7000, 31.8mm Clamp
Shift Levers
Shimano 105 ST-R7025
Cassette
Shimano 105 CS-HG700, 11-34T
Crank
Shimano FC-RS510, 50x34T, 170mm
Chain
Shimano CN-HG601-11
Wheels
Rims
CUBE RA 1.9 Aero Disc, 12x100mm / 12x142mm, 6-Bolt
Tires
Conti Ultra Sport 3, 28-622
Brakes
Brakes
Shimano 105 BR-R7070, Hydr. Disc Brake, Flat Mount (160/160)
Cockpit
Stem
CUBE Performance Stem SL, 31.8mm
Handlebar
CUBE Compact Race Bar
Headset
VP Z-t, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/4"
Seat
Saddle
Natural Fit Venec Lite WS
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.5 mm | 1.54 mm |
| Bottom Bracket Height | 262 mm | 262 mm | 262 mm | 262 mm |
| Front Center | 576 mm | 581 mm | 591 mm | 605 mm |
| Rake | 45 mm | 50 mm | 50 mm | 50 mm |
| Trail | 72 mm | 61 mm | 58 mm | 54 mm |
| Stack | 521 mm | 534 mm | 557 mm | 587 mm |
| Reach | 361 mm | 365 mm | 372 mm | 381 mm |
| Top Tube Length | 506 mm | 513 mm | 533 mm | 556 mm |
| Seat Tube Angle | 74.6 ° | 74.6 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 70.6 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 130 mm | 152 mm | 182 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 976 mm | 981 mm | 991 mm | 1005 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 696 mm | 719 mm | 746 mm | 776 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
AXIAL WS Race completes the Cube Axial model. CUBE launched 50 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the CUBE AXIAL WS 2021 has a starting price of 848$. CUBE AXIAL WS C:62 SL 2021 on the other hand is the most expensive at 2919$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2021 and its price was 1539$. If we compare this with the average Endurance bike cost we notice that the price is 52.44% lower.
Average weight for Endurance bikes
Endurance bikes weigh an average of 8.2 kg (18.08 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 9.9 kg (21.83 lbs), the AXIAL WS Race model is much heavier than average. In conclusion, the average Endurance bike weighs 20.73% less than AXIAL WS Race.
AXIAL WS Race components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on AXIAL WS Race are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AXIAL WS Race comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
AXIAL WS Race comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, you can easily find one that suits you.
