Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite, Double Butted, Advanced Mechanical Forming, Smooth Welded, Internal Cable Routing, Flat Mount Disc, 12x142mm, AXH
Suspension Fork
CUBE Cross Race Disc, Carbon, 1 1/8" - 1 1/2" Tapered, Flat Mount
Drivetrain
Rear Derailleur
Shimano 105 RD-5800GS, 11-Speed
Front Derailleur
Shimano 105 FD-5801, 31.8mm Clamp
Shift Levers
Shimano 105 ST-5800
Cassette
Shimano 105 CS-5800, 11-32T
Crank
Shimano FC-RS510, 50x34T, 170mm (50/53cm), 172.5mm (56cm), 175mm (58/61cm)
Chain
Shimano CN-HG601-11
Wheels
Rims
CUBE RA 0.8 CX
Tires
Schwalbe X-One Allround, Perf. Kevlar, 33-622
Brakes
Brakes
Tektro Lyra MD-C510, Flat Mount
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Compact Race Bar
Headset
FSA Orbit Z-t ECO, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/2"
Seat
Saddle
CUBE RP 1.0
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.47 mm | 1.51 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 592 mm | 588 mm | 600 mm | 606 mm | 619 mm |
| Rake | 46 mm | 36 mm | 45 mm | 46 mm | 46 mm |
| Trail | 73 mm | 81 mm | 64 mm | 60 mm | 57 mm |
| Stack | 528 mm | 553 mm | 576 mm | 597 mm | 623 mm |
| Reach | 374 mm | 375 mm | 381 mm | 385 mm | 395 mm |
| Top Tube Length | 516 mm | 534 mm | 552 mm | 568 mm | 586 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 530 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 70.8 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 140 mm | 160 mm | 180 mm | 205 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1011 mm | 1007 mm | 1019 mm | 1025 mm | 1038 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
CROSS RACE completes the Cube Cross model. CUBE released 72 bikes variations of this model so far. Take a sneak peek at all Cube Cross bikes models from 2018, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Cyclocross bikes
If we make a quick analysis of the average weight of a Cyclocross bike, we get 8.79 kg (19.38 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
CUBE CROSS RACE it’s weighing 10.4 kg (22.93 lbs). At this weight, is much heavier than average. To sum up, it’s 18.32% heavier than the average weight of Cyclocross bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
CROSS RACE components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the CROSS RACE bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE CROSS RACE is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
