Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite, Double Butted, Advanced Mechanical Forming, Smooth Welded, Internal Cable Routing, Flat Mount Disc, 12x142mm, AXH
Suspension Fork
CUBE Cross Race Disc, Carbon, 1 1/8" - 1 1/2" Tapered, Flat Mount
Drivetrain
Rear Derailleur
Shimano 105 RD-5800GS, 11-Speed
Front Derailleur
Shimano 105 FD-5801, 31.8mm Clamp
Shift Levers
Shimano ST-RS505
Cassette
Shimano 105 CS-5800, 11-32T
Crank
Shimano FC-RS510, 50x34T, 170mm (50/53cm), 172.5mm (56cm), 175mm (58/61cm)
Chain
Shimano CN-HG601-11
Wheels
Rims
CUBE RA 0.8 CX
Tires
Schwalbe X-One Allround, Perf. Kevlar, 33-622
Brakes
Brakes
Shimano BR-RS505, Hydr. Disc Brake, Flat Mount (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Compact Race Bar
Headset
FSA Orbit Z-t ECO, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/2"
Seat
Saddle
CUBE RP 1.0
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.47 mm | 1.51 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 592 mm | 588 mm | 600 mm | 606 mm | 619 mm |
| Rake | 46 mm | 36 mm | 45 mm | 46 mm | 46 mm |
| Trail | 73 mm | 81 mm | 64 mm | 60 mm | 57 mm |
| Stack | 528 mm | 553 mm | 576 mm | 597 mm | 623 mm |
| Reach | 374 mm | 375 mm | 381 mm | 385 mm | 395 mm |
| Top Tube Length | 516 mm | 534 mm | 552 mm | 568 mm | 586 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 530 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 70.8 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 140 mm | 160 mm | 180 mm | 205 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1011 mm | 1007 mm | 1019 mm | 1025 mm | 1038 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
CROSS RACE Pro is part of the Cube Cross model. CUBE launched 72 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Cyclocross bikes
Our math shows that the average cost of a dependable Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Cyclocross bikes
Cyclocross bikes weigh an average of 8.79 kg (19.38 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 10.3 kg (22.71 lbs), the CROSS RACE Pro model is much heavier than average. To sum up, it’s 17.18% heavier than the average weight of Cyclocross bikes.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
CROSS RACE Pro components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the CROSS RACE Pro model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
