Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 180mm -
Fork Fox Float 36
-
Groupset X1, e*thirteen TRS -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPA Ultralight, Advanced Hydroform, Triple Butted, ETC 4-Link, ISCG Mount, AXH
Suspension Fork
Fox 36 Float FIT4, Open/Medium/Firm Mode, 20mm Axle, Tapered, 180mm
Rear Shock
Fox Float X Performance 3-Position, 215x64mm, Open/Medium/Firm Mode
Drivetrain
Rear Derailleur
SRAM X1, Type2, 11-Speed
Front Derailleur
e*thirteen TRS 1X Chain Guide, ISCG05
Shift Levers
SRAM GX Trigger
Cassette
SRAM XG-1150, 10-42T
Crank
Race Face Aeffect SL 32T, 175mm
Chain
SRAM 11-Speed
Wheels
Rims
Answer Atac EM, 15mm / X12, 584x25C, Tubeless Ready
Tires
Conti Trail King, folding, 2.4
Brakes
Brakes
SRAM Guide R, Hydr. Disc Brake (200/180)
Cockpit
Stem
Race Face Ride 35
Handlebar
Race Face Chester 35, 780mm
Grips
CUBE Race Grip, 1-Clamp
Headset
FSA 1.5E ZS, Tapered, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
Seat
Saddle
SDG FLY MTN 2
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm, 458x150mm (400x120mm for smallest frame size)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.44 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 351 mm | 351 mm | 351 mm | 351 mm |
| Front Center | 734 mm | 755 mm | 774 mm | 787 mm |
| Rake | 43 mm | 44 mm | 44 mm | 44 mm |
| Trail | 115 mm | 114 mm | 114 mm | 114 mm |
| Stack | 616 mm | 625 mm | 634 mm | 652 mm |
| Reach | 417 mm | 433 mm | 448 mm | 453 mm |
| Top Tube Length | 577 mm | 597 mm | 615 mm | 626 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 390 mm | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 113 mm | 123 mm | 133 mm | 153 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1181 mm | 1202 mm | 1221 mm | 1234 mm |
| Bottom Bracket Drop | 4 mm | 4 mm | 4 mm | 4 mm |
| Rear Travel | 180 mm | 180 mm | 180 mm | 180 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
FRITZZ 180 HPA Race 27.5 completes the Cube Fritzz model. There are 4 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Enduro bikes average weight
Enduro bikes weigh an average of 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
slightly lighter than average, FRITZZ 180 HPA Race 27.5 has a weight of 14.05 kg (30.97 lbs). To sum up, it’s 1.57% lighter than the average weight of Enduro bikes.
Overview of components
Fork
The FRITZZ 180 HPA Race 27.5 comes factory-installed with the Fox Float 36 fork. This has a travel range of 180mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The FRITZZ 180 HPA Race 27.5 has a rear shock with a travel of 180mm. The model Fox Float X Performance 3-Position is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, CUBE FRITZZ 180 HPA Race 27.5 2017, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The FRITZZ 180 HPA Race 27.5 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Dropper post
CUBE FRITZZ 180 HPA Race 27.5 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
