Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 190mm -
Fork SunTour DUROLUX36
-
Groupset Deore, Race Face -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
158cm - 170cm
18"
168cm - 179cm
20"
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Light, Advanced Mechanical Forming, FSP 4-Link, ISCG Mount
Suspension Fork
Suntour Durolux RC, 20x110mm, Tapered, 180mm
Rear Shock
Fox Van RC, 222x70mm, Rebound & Compression Adjust
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000-DSGS, ShadowPlus, 10-Speed, Direct Mount
Front Derailleur
N/A
Shift Levers
Shimano Deore SL-M6000, Rapidfire-Plus
Cassette
Shimano Deore CS-HG500, 11-42T
Crank
Race Face Chester 32T, 170mm
Bottom Bracket
External, threaded
Chain
KMC X10
Chain Guide
e*thirteen LG1
Pedals
N/A
Wheels
Front Hub
Answer Atac EM, 20mm x 110mm / 12mm x 157mm
Rear Hub
Answer Atac EM, 20mm x 110mm / 12mm x 157mm
Rims
Answer Atac EM, 20x110mm / 12x157mm, Tubeless Ready
Tires
Schwalbe Hans Dampf, Addix Performance, Kevlar, 2.35
Brakes
Brakes
Magura MT5, Hydr. Disc Brake (203mm/180mm)
Brake Levers
Magura MT5
Cockpit
Stem
Race Face Aeffect R 35
Handlebar
Race Face Chester 35, 780mm
Grips
SDG Slater
Headset
FSA 1.5E ZS, Tapered, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
Seat
Saddle
Selle Royal MTB
Seatpost
CUBE Performance Post, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm |
| Front Center | 740 mm | 767 mm | 792 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 121 mm | 121 mm | 121 mm |
| Stack | 599 mm | 603 mm | 612 mm |
| Reach | 399 mm | 424 mm | 444 mm |
| Top Tube Length | 546 mm | 573 mm | 596 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 375 mm | 415 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1158 mm | 1185 mm | 1210 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm |
| Rear Travel | 190 mm | 190 mm | 190 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
HANZZ 190 Race 27.5 belongs to the Cube Hanzz model. 6 bikes variations carry this model name so far. Take a sneak peek at all Cube Hanzz bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
According to our math, the average price for a trustworthy Downhill bike is 3391$. However, even though the average price of a Downhill bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Downhill bikes
On a deeper look, we notice that the average weight of a Downhill bike is 15.89 kg (35.03 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
slightly lighter than average, HANZZ 190 Race 27.5 has a weight of 15.4 kg (33.95 lbs). In short, the average Downhill bike weight is 3.18% higher than this one.
HANZZ 190 Race 27.5 components
Fork
CUBE HANZZ 190 Race 27.5 2018 bike is equipped with the SunTour DUROLUX36 fork, and has 180mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The HANZZ 190 Race 27.5 has a rear shock with a travel of 190mm. The model Fox Van RC is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The HANZZ 190 Race 27.5 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The HANZZ 190 Race 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
HANZZ 190 Race 27.5 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
