Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Deore, Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Urban 29 Double Butted
Suspension Fork
Aluminium Rigid Fork 29" Taper
Drivetrain
Rear Derailleur
Shimano Deore RD-M592, 9-Speed
Front Derailleur
Shimano FD-T3000, Topswing, 31.8mm
Shift Levers
Shimano SL-M3000, Rapidfire-Plus
Cassette
Shimano CS-HG200, 11-34T
Crank
Shimano FC-T3010, 48x36x26T, 175mm, BB-UN100, Chainguard
Chain
KMC X9
Pedals
CUBE PP MTB
Wheels
Front Hub
CUBE K68F
Rear Hub
CUBE K68R
Rims
CUBE UX24, 32H, Disc, Tubeless Ready
Tires
Schwalbe Big Apple, Active, 28x2.35
Brakes
Brakes
Tektro HD-M285, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
CUBE Performance Grip
Headset
FSA Orbit 1.5B ZS-1, Semi-Integrated, Top 1 1/8" Bottom 1 1/2"
Seat
Saddle
Selle Royal Prestige
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.54 mm | 1.59 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm |
| Front Center | 638 mm | 638 mm | 638 mm |
| Rake | 45 mm | 45 mm | 46 mm |
| Trail | 81 mm | 74 mm | 67 mm |
| Stack | 590 mm | 613 mm | 636 mm |
| Reach | 395 mm | 397 mm | 399 mm |
| Top Tube Length | 557 mm | 571 mm | 586 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1105 mm | 1105 mm | 1105 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 |
Model Overview
HYDE belongs to the Cube Hyde model. 33 bikes variations carry this model name so far. Take a sneak peek at all Cube Hyde bikes models from 2017, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Touring bikes
Our math shows that the average cost of a dependable Touring bike is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Touring bikes
If we make a quick analysis of the average weight of a Touring bike, we get 13.35 kg (29.43 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
CUBE HYDE it’s weighing 13.4 kg (29.54 lbs). At this weight, is slightly heavier than average. In conclusion, the average Touring bike weighs 0.37% less than HYDE.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The wheels on HYDE are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE HYDE is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
