Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Nexus, Truvativ -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Urban 29 Double Butted
Suspension Fork
Aluminium Rigid Fork 29" Taper
Drivetrain
Shift Levers
Shimano Nexus SL-8S31
Crank
Truvativ E400, 42T, BB Power Spline, 170mm, Chainguard
Chain
KMC Z51
Pedals
CUBE Aluminium MTB
Wheels
Front Hub
Shimano HB-M3050
Rear Hub
Shimano Nexus SG-C8001-8D, 8-Speed
Rims
CUBE UX24, 32H, Disc, Tubeless Ready
Tires
Schwalbe Big Apple, Active, 28x2.35
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
RFR Comfort
Headset
FSA Orbit 1.5B ZS-1, Semi-Integrated, Top 1 1/8" Bottom 1 1/2"
Seat
Saddle
Selle Royal Prestige
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | 58cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.51 mm | 1.56 mm | 1.6 mm | 1.64 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 637 mm | 637 mm | 637 mm | 647 mm | 658 mm |
| Rake | 44 mm | 44 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82 mm | 75 mm | 68 mm | 68 mm | 68 mm |
| Stack | 581 mm | 604 mm | 627 mm | 646 mm | 669 mm |
| Reach | 398 mm | 400 mm | 402 mm | 405 mm | 408 mm |
| Top Tube Length | 557 mm | 571 mm | 586 mm | 601 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1104 mm | 1104 mm | 1104 mm | 1114 mm | 1125 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
HYDE Pro completes the Cube Hyde model. There are 33 bikes that carry this model name. You can easily view all of the Cube Hyde bikes models from 2017, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Touring bikes
Our math shows that the average cost of a dependable Touring bike is 1007$. However, this doesn’t mean that if you spend less money on a Touring bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Touring bikes
If we make a quick analysis of the average weight of a Touring bike, we get 13.35 kg (29.43 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
CUBE HYDE Pro it’s weighing 13.95 kg (30.75 lbs). At this weight, is slightly heavier than average. To sum up, it’s 4.49% heavier than the average weight of Touring bikes.
HYDE Pro components
Fork material
HYDE Pro has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The HYDE Pro 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE HYDE Pro is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
