Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset Deore, Acera -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Urban 29 Double Butted
Suspension Fork
Aluminium Rigid Fork 29" Taper
Drivetrain
Rear Derailleur
Shimano Deore RD-M592, 9-Speed
Front Derailleur
Shimano Acera FD-T3000, Topswing, 31.8mm
Shift Levers
Shimano SL-M3000
Cassette
Shimano CS-HG200, 11-34T
Crank
Shimano Acera FC-T3010, 48x36x26T, 175mm, BB-UN100, Chainguard
Chain
KMC X9
Pedals
CUBE PP MTB
Wheels
Front Hub
Shimano HB-TX505, QR, Centerlock
Rear Hub
Shimano FH-TX505, QR, Centerlock
Rims
CUBE UX24, 32H, Disc, Tubeless Ready
Tires
Schwalbe Big Apple, Active, 29x2.15
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
CUBE Performance Grip
Headset
FSA Orbit 1.5B ZS-1, Semi-Integrated, Top 1 1/8" Bottom 1 1/2"
Seat
Saddle
Selle Royal Prestige
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.54 mm | 1.59 mm |
| Front Center | 638 mm | 638 mm | 638 mm |
| Rake | 45 mm | 45 mm | 46 mm |
| Trail | 86 mm | 79 mm | 72 mm |
| Stack | 590 mm | 613 mm | 636 mm |
| Reach | 395 mm | 397 mm | 399 mm |
| Top Tube Length | 557 mm | 571 mm | 586 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1105 mm | 1105 mm | 1105 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Wheels | 29" | 29" | 29" |
About this model
HYDE Trapeze belongs to the Cube Hyde model. CUBE released 33 bikes variations of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Hybrid bikes average weight
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.6 kg (29.98 lbs), CUBE bike is slightly lighter than average. In other words, this model is 1.84% lighter than the average Hybrid bike.
HYDE Trapeze components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the HYDE Trapeze bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE HYDE Trapeze is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
