Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 T6 Superlight, Gravel Comfort Geometry, Flat Mount Disc, Fender & Rack Option, 12x142mm, AXH
Suspension Fork
CUBE Nuroad Disc, One Piece 3D-Forged Steerer/Crown, Carbon Blades, 1 1/8" - 1 1/2" Tapered, Flat Mount, 12x100mm
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700GS, 10-Speed
Front Derailleur
Shimano Tiagra FD-4700, 31.8mm Clamp
Shift Levers
Shimano Tiagra ST-4700
Cassette
Shimano CS-HG500, 11-34T
Crank
Shimano Tiagra FC-4700, 50x34T, 170mm (50/53cm), 172.5mm (56/58cm), 175mm (61cm)
Chain
KMC X10
Wheels
Rims
CUBE RA 0.8 CX
Tires
Clément X´Plor MSO Folding, 36-622
Brakes
Brakes
Tektro Spyre MD-C610C, Flat Mount (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Gravel Race Bar
Headset
FSA Orbit Z-t ECO, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/2"
Seat
Saddle
CUBE Race Exc
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.52 mm | 1.56 mm | 1.59 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 598 mm | 603 mm | 612 mm | 617 mm | 628 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 78 mm | 72 mm | 68 mm | 65 mm | 62 mm |
| Stack | 535 mm | 559 mm | 590 mm | 611 mm | 634 mm |
| Reach | 378 mm | 384 mm | 388 mm | 391 mm | 400 mm |
| Top Tube Length | 519 mm | 539 mm | 562 mm | 577 mm | 594 mm |
| Seat Tube Angle | 75.2 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 118 mm | 140 mm | 170 mm | 190 mm | 213 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1020 mm | 1025 mm | 1034 mm | 1039 mm | 1050 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
NUROAD is part of the Cube Nuroad model. CUBE released 50 bikes variations of this model so far. Take a sneak peek at all Cube Nuroad bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Gravel bikes average weight
Gravel bikes weigh an average of 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
CUBE NUROAD it’s weighing 10.7 kg (23.59 lbs). At this weight, is much heavier than average. To sum up, it’s 31.61% heavier than the average weight of Gravel bikes.
Overview of components
Fork material
NUROAD has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the NUROAD model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE NUROAD has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
