Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium 6061 T6 Superlight, Gravel Comfort Geometry, Flat Mount Disc, Fender & Rack Option, 12x142mm, AXH
Suspension Fork
CUBE Nuroad Disc, One Piece 3D-Forged Steerer/Crown, Carbon Blades, 1 1/8" - 1 1/2" Tapered, Flat Mount, 12x100mm
Drivetrain
Rear Derailleur
Shimano 105 RD-5800GS, 11-Speed
Front Derailleur
Shimano 105 FD-5801, 31.8mm Clamp
Shift Levers
Shimano ST-RS505
Cassette
Shimano 105 CS-5800, 11-32T
Crank
Shimano FC-RS510, 50x34T, 170mm (50/53cm), 172.5mm (56/58cm), 175mm (61cm)
Chain
Shimano CN-HG601-11
Wheels
Rims
CUBE RA 0.8 CX
Tires
Clément X´Plor USH Folding, 35-622
Brakes
Brakes
Shimano BR-RS505, Hydr. Disc Brake, Flat Mount (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Gravel Race Bar
Headset
FSA Orbit Z-t ECO, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/2"
Seat
Saddle
CUBE Race Exc
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.52 mm | 1.56 mm | 1.59 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 598 mm | 603 mm | 612 mm | 617 mm | 628 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 78 mm | 72 mm | 68 mm | 65 mm | 62 mm |
| Stack | 535 mm | 559 mm | 590 mm | 611 mm | 634 mm |
| Reach | 378 mm | 384 mm | 388 mm | 391 mm | 400 mm |
| Top Tube Length | 519 mm | 539 mm | 562 mm | 577 mm | 594 mm |
| Seat Tube Angle | 75.2 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 118 mm | 140 mm | 170 mm | 190 mm | 213 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1020 mm | 1025 mm | 1034 mm | 1039 mm | 1050 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
NUROAD Exc is a Cube Nuroad model. CUBE released 50 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Gravel bikes average weight
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
much heavier than average, NUROAD Exc has a weight of 11.9 kg (26.23 lbs). In conclusion, the average Gravel bike weighs 46.37% less than NUROAD Exc.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the NUROAD Exc bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The NUROAD Exc has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
