Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" / 27.5" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset XT -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
GTC Twin Mold Monocoque Technology, ARG2, Tapered Headtube, PressFit BB, X12, Integrated Cable Routing
Suspension Fork
Fox 32 Float Performance SC, 15QR Boost, Tapered, Remote Lockout, 100mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-DSGS, ShadowPlus, 11-Speed, Direct Mount
Front Derailleur
Shimano XT FD-M8020-D, Direct Mount, Side Swing
Shift Levers
Shimano XT SL-M8000-I, Direct Attach
Cassette
Shimano XT CS-M8000, 11-42T
Crank
Shimano XT FC-M8000, 36x26T, 175mm
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-HG601-11
Wheels
Rims
Fulcrum Red 66, 28/28Spokes, 15QR/X12
Tires
Schwalbe Rocket Ron, Kevlar, 2.25, LiteSkin
Brakes
Brakes
Shimano XT BR-M8000, Hydr. Disc Brake (180/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar Pro, 720mm
Grips
CUBE Race Grip, 1-Clamp
Headset
FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
Selle Italia SC1
Seatpost
CUBE Prolight, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 16" | 17" | 18" | 19" | 21" | 23" |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.54 mm | 1.41 mm | 1.5 mm | 1.46 mm | 1.47 mm |
| Bottom Bracket Height | 309 mm | 304 mm | 309 mm | 304 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 646 mm | 640 mm | 658 mm | 663 mm | 680 mm | 700 | 711 mm |
| Rake | 51 mm | 44 mm | 50 mm | 44 mm | 51 mm | 51 mm | 50 mm |
| Trail | 86 mm | 83 mm | 83 mm | 83 mm | 82 mm | 82 mm | 83 mm |
| Stack | 610 mm | 589 mm | 622 mm | 594 mm | 631 mm | 641 mm | 655 mm |
| Reach | 390 mm | 401 mm | 404 mm | 422 mm | 422 mm | 438 mm | 445 mm |
| Top Tube Length | 574 mm | 574 mm | 591.5 mm | 597 mm | 613 mm | 632 mm | 643 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 73 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 370 mm | 405 mm | 420 mm | 450 mm | 470 mm | 515 mm | 565 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 100 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 439 mm | 428 mm | 439 mm | 428 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1077 mm | 1063 mm | 1089 mm | 1086 mm | 1111 mm | 1131 mm | 1142 mm |
| Bottom Bracket Drop | 65 mm | 51 mm | 65 mm | 51 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 29" | 27" | 29" | 27" | 29" | 29" | 29" |
About this model
REACTION GTC SL completes the Cube Reaction model. CUBE launched 76 bikes of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
CUBE REACTION GTC SL it’s weighing 10.55 kg (23.26 lbs). At this weight, is much lighter than average. To sum up, it’s 17.54% lighter than the average weight of Crosscountry bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The REACTION GTC SL comes factory-installed with the Fox Performance Float 32 fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on REACTION GTC SL are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
