Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Groupset 105 -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Crossroad Taper Double Butted
Suspension Fork
CUBE Road Race, Carbon, Disc, Taper, 63mm
Drivetrain
Rear Derailleur
Shimano 105 RD-5800GS, 11-Speed
Front Derailleur
Shimano 105 FD-5800, 31.8mm Clamp
Shift Levers
Shimano SL-RS700
Cassette
Shimano 105 CS-5800, 11-32T
Crank
Shimano 105 FC-5800-L, Hollowtech II, 50x34T, BB Integrated
Chain
Shimano CN-HG601-11
Pedals
CUBE Aluminium MTB
Wheels
Rims
Fulcrum Racing 77, Centerlock, QR/QR
Tires
Schwalbe Kojak, Active, 35x622
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
CUBE Natural Fit Race
Headset
FSA Orbit Z-t ECO, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/2"
Seat
Saddle
Cube Active 1.1
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.45 mm | 1.46 mm | 1.5 mm |
| Front Center | 607 mm | 612 mm | 616 mm | 635 mm | 655 mm |
| Rake | 45 mm | 44 mm | 45 mm | 44 mm | 45 mm |
| Trail | 76 mm | 70 mm | 66 mm | 67 mm | 66 mm |
| Stack | 526 mm | 549 mm | 565 mm | 589 mm | 618 mm |
| Reach | 381 mm | 388 mm | 391 mm | 403 mm | 413 mm |
| Top Tube Length | 534 mm | 558 mm | 566 mm | 585 mm | 604 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 145 mm | 160 mm | 185 mm | 215 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1022 mm | 1027 mm | 1031 mm | 1050 mm | 1070 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
SL ROAD Race belongs to the Cube Sl model. 43 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fitness bikes average price
If you want an acceptable Fitness bike you should know that the average price is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Fitness bikes
Fitness bikes weigh an average of 11.24 kg (24.78 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 10.25 kg (22.6 lbs), CUBE bike is a bit lighter than average. To sum up, it’s 9.66% lighter than the average weight of Fitness bikes.
Overview of components
Fork material
SL ROAD Race has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, CUBE SL ROAD Race 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE SL ROAD Race is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
