Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Crossroad Taper Double Butted
Suspension Fork
Aluminium Rigid Fork
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000-SS, 8-Speed
Front Derailleur
Shimano Claris FD-R2000-BM, 31.8mm
Shift Levers
Shimano Claris SL-R2000
Cassette
Shimano CS-HG200, 12-32T
Crank
Shimano Claris FC-R2000, 50x34T, BB-RS500
Bottom Bracket
BSA, 68mm, threaded
Chain
KMC Z51
Pedals
CUBE PP MTB
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505, Centerlock
Rims
CUBE ZX20, 32H, Disc
Tires
Schwalbe CX Comp, 40x622
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
CUBE Performance Grip
Headset
FSA Orbit Z-t ECO, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/2"
Seat
Saddle
Selle Royal MTB
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.39 mm | 1.39 mm |
| Front Center | 597 mm | 608 mm | 623 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 76 mm | 69 mm |
| Stack | 524 mm | 535 mm | 558 mm |
| Reach | 372 mm | 384 mm | 401 mm |
| Top Tube Length | 513 mm | 533 mm | 557 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1016 mm | 1027 mm | 1042 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 |
About this model
SL ROAD Trapeze is part of the Cube Sl model. CUBE launched 43 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Fitness bikes
Fitness bikes weigh an average of 11.24 kg (24.78 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
slightly heavier than average, SL ROAD Trapeze has a weight of 11.8 kg (26.01 lbs). In conclusion, the average Fitness bike weighs 4.98% less than SL ROAD Trapeze.
SL ROAD Trapeze components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The wheels on SL ROAD Trapeze are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE SL ROAD Trapeze has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
