Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Manitou Markhor
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPA Ultralight, Advanced Hydroform, Triple Butted, ATG, ETC 4-Link, AXH
Suspension Fork
Manitou Markhor Air, Tapered, 15x110mm, 120mm
Rear Shock
Manitou Radium Expert RL, 184x44mm, Rebound Adjust, Lockout
Drivetrain
Rear Derailleur
Shimano XT RD-M781-DSGSL, Shadow, 10-Speed
Front Derailleur
Shimano Deore FD-M617-D, Direct Mount, Side Swing
Shift Levers
Shimano Deore SL-M610, Rapidfire-Plus
Cassette
Shimano CS-HG50, 11-36T
Crank
Shimano Deore FC-M617, 36x22T, 175mm
Bottom Bracket
Pressfit
Chain
KMC X10
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Answer Atac MA, 15mm / X12
Rear Hub
Answer Atac MA, 15mm / X12
Rims
Answer Atac MA, 28/28 Spokes, 15mm / X12, Tubeless Ready
Spokes
28 / 28 spoke count
Tires
Schwalbe Nobby Nic, Addix Performance, Kevlar, 2.25
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (180/180)
Brake Levers
Shimano BR-M315
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
Cube Rise Trail Bar Pro, 720mm
Grips
CUBE Race SL Grip 29.5, 1-Clamp
Headset
FSA 1.5E ZS, Tapered, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
Seat
Saddle
Selle Royal MTB
Seatpost
CUBE Performance Post, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" | 23" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.44 mm | 1.41 mm | 1.44 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Front Center | 699 mm | 719 mm | 738 mm | 750 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 93 mm | 93 mm | 93 mm | 93 mm |
| Stack | 608 mm | 618 mm | 627 mm | 646 mm |
| Reach | 414 mm | 430 mm | 445 mm | 450 mm |
| Top Tube Length | 571 mm | 590 mm | 608 mm | 619 mm |
| Seat Tube Angle | 75.2 ° | 75.2 ° | 75.2 ° | 75.2 ° |
| Seat Tube Length | 395 mm | 445 mm | 495 mm | 545 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1138 mm | 1158 mm | 1177 mm | 1189 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
STEREO 120 29 belongs to the Cube Stereo 120 model. CUBE released 38 bikes variations of this model so far. You can easily view all of the Cube Stereo 120 bikes models from 2018, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
The average weight for Trail bikes is 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.4 kg (29.54 lbs), CUBE bike is slightly heavier than average. In conclusion, the average Trail bike weighs 3.24% less than STEREO 120 29.
STEREO 120 29 components
Fork
This bike has the Manitou Markhor fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
CUBE STEREO 120 29 bike has the Manitou Radium Expert RL model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The STEREO 120 29 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE STEREO 120 29 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
