Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
158cm - 170cm
18"
168cm - 179cm
20"
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPC Carbon Monocoque Advanced Twin Mold Technology, Aluminum 6061 T6 Rear Triangle, ATG, ETC 4-Link, AXH
Suspension Fork
Fox 32 Rhythm, 2-Position Sweep-Adjust GRIP Damper, Tapered, 15x110mm, 120mm
Rear Shock
Fox Float DPS EVOL, 184x44mm, Open/Medium/Firm Mode
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-DSGS, ShadowPlus, 11-Speed
Front Derailleur
Shimano SLX FD-M7020-D, Direct Mount, Side Swing
Shift Levers
Shimano SLX SL-M7000-I, Direct Attach
Cassette
Shimano SLX CS-M7000, 11-42T
Crank
Shimano XT FC-M8000, 27.5": 36x26T // 29": 34x24T, 175mm (180mm for 23" frame size)
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X11
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Fulcrum Red 55, 15mm x 110mm / 12mm x 142mm
Rear Hub
Fulcrum Red 55, 15mm x 110mm / 12mm x 142mm
Rims
Fulcrum Red 55, 28/28 Spokes, 15x110mm / 12x142mm
Spokes
28 / 28 spoke count
Tires
Schwalbe Nobby Nic, Addix Performance, Kevlar, 2.25
Brakes
Brakes
Shimano XT BR-M8000, Hydr. Disc Brake (180/180)
Brake Levers
Shimano XT BR-M8000
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar Pro, 740mm
Grips
CUBE Race SL Grip 29.5, 1-Clamp
Headset
FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
Selle Italia X3
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm, 458x150mm (400x120mm for smallest frame size)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" |
|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Front Center | 680 mm | 701 mm | 719 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 93 mm | 93 mm | 93 mm |
| Stack | 573 mm | 583 mm | 592 mm |
| Reach | 403 mm | 420 mm | 435 mm |
| Top Tube Length | 559 mm | 579 mm | 597 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 375 mm | 420 mm | 470 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1099 mm | 1120 mm | 1138 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
STEREO 120 HPC SL 27.5 completes the Cube Stereo 120 model. CUBE launched 38 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
Trail bikes have an average weight of 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 12.7 kg (28 lbs), the STEREO 120 HPC SL 27.5 model is slightly lighter than average. To sum up, it’s 2.2% lighter than the average weight of Trail bikes.
Overview of components
Fork
CUBE STEREO 120 HPC SL 27.5 2018 bike is equipped with the Fox Rhythm Float 32 fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Fox Float DPS EVOL model, with a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, CUBE STEREO 120 HPC SL 27.5 2018, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE STEREO 120 HPC SL 27.5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
CUBE STEREO 120 HPC SL 27.5 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
CUBE STEREO 120 HPC SL 27.5 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
