Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Factory Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
19"
165cm - 177cm
21"
175cm - 188cm
23"
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPC Carbon Monocoque Advanced Twin Mold Technology, Aluminum 6061 T6 Rear Triangle, ATG, ETC 4-Link, AXH
Suspension Fork
Fox 32 Float Factory FIT4, Open(Adjustable)/Medium/Firm Mode, Tapered, 15x110mm, 120mm, Kashima Coated
Rear Shock
Fox Float DPS Factory EVOL, 184x44mm, Open(Adjustable)/Medium/Firm Mode, Kashima Coated
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-DSGS, ShadowPlus, 11-Speed
Front Derailleur
Shimano XT FD-M8020-D, Side Swing
Shift Levers
Shimano XT SL-M8000-I, Direct Attach
Cassette
Shimano SLX CS-M7000, 11-42T
Crank
Shimano XT FC-M8000, 27.5": 36x26T // 29": 34x24T, 175mm (180mm for 23" frame size)
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-HG601-11
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Newmen Evolution SL A.25, 15mm x 110mm / 12mm x 148mm
Rear Hub
Newmen Evolution SL A.25, 15mm x 110mm / 12mm x 148mm
Rims
Newmen Evolution SL A.25, 28/28 Spokes, 15x110mm / 12x148mm, Tubeless Ready
Spokes
28 / 28 spoke count
Tires
Schwalbe Nobby Nic, Addix Speedgrip, Kevlar, Tubeless Easy, 2.25
Brakes
Brakes
Shimano XT BR-M8000, Hydr. Disc Brake (180/180)
Brake Levers
Shimano XT BR-M8000
Cockpit
Stem
Newmen Evolution SL 318.4, 31.8mm
Handlebar
Newmen Advanced 318.20, 740mm
Grips
CUBE Race SL Grip 29.5, 1-Clamp
Headset
FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
CUBE Race SL Carbon 145
Seatpost
Fox Transfer Factory 31.6mm, Kashima coated, 456x150mm (409x125mm for smallest frame size)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 19" | 21" | 23" |
|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.41 mm | 1.44 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm |
| Front Center | 719 mm | 738 mm | 750 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 93 mm | 93 mm | 93 mm |
| Stack | 617 mm | 626 mm | 645 mm |
| Reach | 429 mm | 444 mm | 449 mm |
| Top Tube Length | 589 mm | 607 mm | 618 mm |
| Seat Tube Angle | 75.2 ° | 75.2 ° | 75.2 ° |
| Seat Tube Length | 445 mm | 495 mm | 545 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1157 mm | 1176 mm | 1188 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
STEREO 120 HPC SLT 29 is part of the Cube Stereo 120 model. CUBE launched 38 bikes of this model so far. You can easily view all of the Cube Stereo 120 bikes models from 2018, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
STEREO 120 HPC SLT 29 weighs 12.3 kg (27.12 lbs) and is a bit lighter than the average. To sum up, it’s 5.53% lighter than the average weight of Trail bikes.
Overview of components
Fork
CUBE STEREO 120 HPC SLT 29 2018 bike is equipped with the Fox Factory Float 32 fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the Fox Float DPS Factory EVOL rear shock model, which has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The STEREO 120 HPC SLT 29 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE STEREO 120 HPC SLT 29 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
STEREO 120 HPC SLT 29 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
