Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
158cm - 170cm
18"
168cm - 179cm
20"
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPA Ultralight, Advanced Hydroform, Triple Butted, ATG, ETC 4-Link, AXH
Suspension Fork
Fox 32 Rhythm, 2-Position Sweep-Adjust GRIP Damper, Tapered, 15x110mm, 120mm
Rear Shock
Fox Float DPS EVOL, 184x44mm, Open/Medium/Firm Mode
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-DSGS, ShadowPlus, 11-Speed
Front Derailleur
Shimano SLX FD-M7020-D, Direct Mount, Side Swing
Shift Levers
Shimano SLX SL-M7000-I, Direct Attach
Cassette
Shimano SLX CS-M7000, 11-42T
Crank
Shimano XT FC-M8000, 27.5": 36x26T // 29": 34x24T, 175mm (180mm for 23" frame size)
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC X11
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Fulcrum Red 55, 15mm x 110mm / 12mm x 142mm
Rear Hub
Fulcrum Red 55, 15mm x 110mm / 12mm x 142mm
Rims
Fulcrum Red 55, 28/28 Spokes, 15x110mm / 12x142mm
Spokes
28 / 28 spoke count
Tires
Schwalbe Nobby Nic, Addix Performance, Kevlar, 2.25
Brakes
Brakes
Shimano XT BR-M8000, Hydr. Disc Brake (180/180)
Brake Levers
Shimano XT BR-M8000
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar Pro, 740mm
Grips
CUBE Race SL Grip 29.5, 1-Clamp
Headset
FSA 1.5E ZS, Tapered, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
Seat
Saddle
Selle Italia X3
Seatpost
CUBE Performance Post, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" |
|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.36 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Front Center | 680 mm | 701 mm | 719 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 93 mm | 93 mm | 93 mm |
| Stack | 573 mm | 583 mm | 592 mm |
| Reach | 403 mm | 420 mm | 435 mm |
| Top Tube Length | 559 mm | 579 mm | 597 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 375 mm | 420 mm | 470 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1099 mm | 1120 mm | 1138 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
STEREO 120 Race 27.5 belongs to the Cube Stereo 120 model. 38 bikes variations carry this model name so far. Take a sneak peek at all Cube Stereo 120 bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Trail bikes average weight
The average weight for Trail bikes is 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 12.9 kg (28.44 lbs), CUBE bike is slightly lighter than average. To sum up, it’s 0.62% lighter than the average weight of Trail bikes.
Overview of components
Fork
The STEREO 120 Race 27.5 comes factory-installed with the Fox Rhythm Float 32 fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The STEREO 120 Race 27.5 has a rear shock with a travel of 120mm. The model Fox Float DPS EVOL is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the STEREO 120 Race 27.5 bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The STEREO 120 Race 27.5 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
STEREO 120 Race 27.5 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
