CUBE STEREO HYBRID 120 HPC TM 500 2019
2019 E-bike
Estimate price |
5,160$
Weight | 23 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" / 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Float 34
-
Groupset XT, Race Face -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube 500 -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
C:62 Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control 4-Link, Agile Trail Geometry, Boost 148, Tuned Drive Position, AXH, Full Integrated Battery
Suspension Fork
Fox 34 Float, 3-Position Micro-Adjust GRIP Damper, Tapered, E-Bike Optimized, 15x110mm, 130mm; 16": 140mm
Rear Shock
Fox Float DPS EVOL, 184x44mm, Open/Medium/Firm Mode
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-DGS, ShadowPlus, 11-Speed
Front Derailleur
N/A
Shift Levers
Shimano XT SL-M8000-I, Direct Attach
Cassette
Shimano SLX CS-M7000, 11-46T
Crank
Race Face Aeffect, 15T, 170mm
Chain
KMC X11e, EcoProTeQ
Chain Guide
N/A
Pedals
CUBE PP MTB
Wheels
Front Hub
Shimano XT HB-M8010-B, 15QR, Boost, Centerlock
Rear Hub
Shimano XT FH-M8010-B, 12mm, Boost, Centerlock
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Tires
Schwalbe Hans Dampf 2.60, Addix Speedgrip, Apex, Tubeless Easy
Brakes
Brakes
Shimano XT BR-MT8020/BR-M8000, Hydr. Disc Brake (203/180)
Brake Levers
Shimano XT BR-MT8020/BR-M8000
Cockpit
Stem
Newmen Evolution 318.4, 31.8mm
Handlebar
Newmen Evolution 318.20, 760mm
Grips
SDG Slater
Headset
FSA Orbit I-t, Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
Natural Fit Active Race
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm (16": 370x100mm, 18": 420x125mm, 20", 22": 480x150mm)
Motor & Battery
Motor
Bosch Drive Unit Performance CX (75Nm) Cruise (250Watt)
Battery
Bosch PowerTube 500
Remote
Bosch Purion
Charger
Bosch 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.45 mm | 1.42 mm | 1.42 mm |
| Bottom Bracket Height | 326 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 677 mm | 705 mm | 724 mm | 744 mm |
| Rake | 44 mm | 50 mm | 51 mm | 51 mm |
| Trail | 93 mm | 97 mm | 96 mm | 96 mm |
| Stack | 592 mm | 600 mm | 609 mm | 628 mm |
| Reach | 403 mm | 415 mm | 430 mm | 442 mm |
| Top Tube Length | 570.5 mm | 590 mm | 608 mm | 626 mm |
| Seat Tube Angle | 73.7 ° | 73.2 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 473 mm | 487 mm | 487 mm | 487 mm |
| Wheelbase | 1149 mm | 1190 mm | 1209 mm | 1229 mm |
| Bottom Bracket Drop | 29 mm | 30 mm | 30 mm | 30 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 29" | 29" | 29" |
Model Overview
STEREO HYBRID 120 HPC TM 500 is a Cube E Stereo Hybrid 120 model. There are 83 e-bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
The most economical model, the CUBE STEREO HYBRID 120 Pro 500 2019 has a starting price of 3397$. CUBE STEREO HYBRID 120 HPC SLT 500 2019 on the other hand is the most expensive at 6901$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4777$. Doing a quick comparison, we notice that STEREO HYBRID 120 HPC TM 500 price is 41.96% higher than the average cost of a Trail e-bike.
Average weight for Trail e-bikes
The average weight for Trail e-bikes is 23.7 kg (52.25 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
STEREO HYBRID 120 HPC TM 500 weighs 23 kg (50.71 lbs) and is slightly lighter than the average. To sum up, it’s 3.04% lighter than the average weight of Trail e-bikes.
STEREO HYBRID 120 HPC TM 500 components
Fork
The Fox Float 34 is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the Fox Float DPS EVOL model, with a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The STEREO HYBRID 120 HPC TM 500 2019 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the e-bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE STEREO HYBRID 120 HPC TM 500 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
The CUBE model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
