CUBE STEREO HYBRID 140 HPC ACTIONTEAM 625 29 2020
2020 E-bike
Estimate price |
6,707$
Weight | 23.6 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Fox Factory Float 36
-
Groupset XT, e*thirteen -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery PowerTube 625 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPC, High Performance Composite
Suspension Fork
Fox 36 Float Factory FIT4, E-Bike Tune, 150mm
Rear Shock
Fox Float DPX2 Factory EVOL
Drivetrain
Rear Derailleur
Shimano XT, 10-51T, 1x12
Shift Levers
Shimano XT SL-M8100-IR, Direct Attach
Cassette
Shimano SLX CS-M7100, 10-51T
Crank
e*thirteen Plus Crank, 34T
Chain
Shimano SLX CN-M7100
Chain Guide
e*thirteen Plus e*spec
Wheels
Front Hub
Shimano XT HB-M8110-B, 15QR, Boost, Centerlock
Rear Hub
Shimano XT FH-M8110-B, 12mm, Boost, Centerlock
Rims
Newmen Evolution SL E.35, 28H, Disc, Tubeless Ready
Tires
Schwalbe Magic Mary, Addix Soft, Super Gravity, Tubeless Easy, 2.60
Brakes
Brakes
Shimano XT BR-M8120
Cockpit
Stem
Race Face Turbine R 35
Handlebar
Race Face Next R 35 Carbon, 800mm
Grips
CUBE Race Grip 31mm, 1-Clamp
Headset
FSA Orbit Z 1.5E ZS, Top Zero-Stack 1 1/2" (OD 56mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
Seat
Saddle
Natural Fit Venec
Seatpost
Fox Transfer Factory 31.6mm, Kashima Coated (16": 359x100mm; 18": 409x125mm; 20", 22": 456x150mm)
Motor & Battery
Motor
Bosch Drive Unit Performance CX GEN4 (75Nm)
Battery
PowerTube 625
Remote
Kiox
Charger
4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm | 1.4 mm | 1.38 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 734 mm | 755 mm | 780 mm | 807 mm |
| Rake | 52 mm | 52 mm | 52 mm | 51 mm |
| Trail | 113 mm | 113 mm | 113 mm | 114 mm |
| Stack | 609 mm | 612 mm | 621 mm | 639 mm |
| Reach | 403 mm | 423 mm | 444 mm | 463 mm |
| Top Tube Length | 563 mm | 584 mm | 608 mm | 634 mm |
| Seat Tube Angle | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° |
| Seat Tube Length | 375 mm | 420 mm | 470 mm | 520 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 105 mm | 108 mm | 118 mm | 138 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1181 mm | 1202 mm | 1227 mm | 1254 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 769 mm | 769 mm | 769 mm | 805 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
STEREO HYBRID 140 HPC ACTIONTEAM 625 29 completes the Cube E Stereo Hybrid 140 model. CUBE released 64 e-bikes variations of this model so far. Take a sneak peek at all Cube E Stereo Hybrid 140 e-bikes models from 2020, by clicking here.
Model range prices
CUBE STEREO HYBRID 140 HPC RACE 500 29 2020 is the cheapest e-bike model and costs 3829$. CUBE STEREO HYBRID 140 HPC SLT 625 29 2020 is the most expensive one and costs 8279$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When CUBE released this model in 2020, its price was 6209$. Comparing this to the average Trail e-bike price, we see that the price is 84.52% higher.
Trail e-bikes average weight
Trail e-bikes have an average weight of 23.7 kg (52.25 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 23.6 kg (52.03 lbs), CUBE e-bike is slightly lighter than average. To sum up, it’s 0.42% lighter than the average weight of Trail e-bikes.
STEREO HYBRID 140 HPC ACTIONTEAM 625 29 components
Fork
This e-bike has the Fox Factory Float 36 fork installed. The fork’s travel is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The STEREO HYBRID 140 HPC ACTIONTEAM 625 29 has a rear shock with a travel of 140mm. The model Fox Float DPX2 Factory EVOL is the one installed in this e-bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on STEREO HYBRID 140 HPC ACTIONTEAM 625 29 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The STEREO HYBRID 140 HPC ACTIONTEAM 625 29 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
CUBE STEREO HYBRID 140 HPC ACTIONTEAM 625 29 includes a dropper post. Therefore, climbing or descending will be a breeze.
