Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork SunTour XCR 32 Air
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour XCR32 Air Disc, 15QR x 110mm
Rear Shock
Suntour UNAir LOR8, 184mm x 44mm, 30x8mm upper mount, 22x8mm lower mount
Drivetrain
Rear Derailleur
Shimano XT RD-M781-DSGSL, Shadow, 10-speed
Front Derailleur
Shimano Deore FD-M617-D, direct mount, side swing
Shift Levers
Shimano Deore SL-M6000, Rapidfire Plus
Cassette
Shimano CS-HG50, 11-36 tooth, 10-speed
Crank
Shimano Deore FC-M617, 175mm
Bottom Bracket
Press-fit
Chain
KMC X10
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Front: Shimano HB-MT400, 15QR x 110mm, Rear: Shimano FH-MT400, through axle, 12mm x 148mm
Rear Hub
Front: Shimano HB-MT400, 15QR x 110mm, Rear: Shimano FH-MT400, through axle, 12mm x 148mm
Rims
Cube EX21, 32 hole, tubeless ready
Tires
Front: Schwalbe Tough Tom, Active, 29 x 2.25" (27.5 x 2.25" for 13.5" and 16" frame), Rear: Schwalbe Rapid Rob, Active, 29 x 2.25" (27.5 x 2.25" for 13.5" and 16" frame)
Brakes
Brakes
Shimano BR-MT200 with 180mm rotors (front and rear)
Brake Levers
Shimano BR-MT200
Cockpit
Stem
Cube Performance Pro, 31.8mm diameter
Handlebar
Cube Rise Trail, 700mm width
Grips
Cube Performance
Headset
FSA 1.5E ZS, zero stack
Seat
Saddle
Cube Natural Fit Active WS
Seatpost
Cube Performance
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 16" | 17" | 19" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.41 mm | 1.46 mm | 1.43 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 313 mm | 313 mm |
| Front Center | 659 mm | 680 mm | 700 | 720 mm |
| Rake | 44 mm | 44 mm | 51 mm | 51 mm |
| Trail | 93 mm | 93 mm | 85 mm | 85 mm |
| Stack | 580 mm | 584 mm | 616 mm | 626 mm |
| Reach | 395 mm | 414 mm | 422 mm | 438 mm |
| Top Tube Length | 549 mm | 569.5 mm | 579 mm | 598 mm |
| Seat Tube Angle | 74.74 ° | 74.74 ° | 75.23 ° | 75.23 ° |
| Seat Tube Length | 335 mm | 375 mm | 395 mm | 445 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 431 mm | 431 mm | 449 mm | 449 mm |
| Wheelbase | 1089 mm | 1110 mm | 1146 mm | 1166 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 42 mm | 42 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
Sting 120 WS EXC is part of the Cube Sting model. Cube released 27 bikes variations of this model so far. You can easily view all of the Cube Sting bikes models from 2019, here.
Model range prices
CUBE STING WS 120 Exc 2019 is the most economical model, with a starting price of 1485$. CUBE STING WS 140 HPC SL 27.5 2019 on the other hand costs 3715$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Cube Sting 120 WS EXC it’s weighing 13.8 kg (30.42 lbs). At this weight, is a bit heavier than average. To sum up, it’s 6.32% heavier than the average weight of Trail bikes.
Sting 120 WS EXC components
Fork
The SunTour XCR 32 Air is included from the factory. It has a travel distance of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Cube Sting 120 WS EXC bike has the Suntour UNAir LOR8 model installed, and has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the Sting 120 WS EXC model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Cube Sting 120 WS EXC has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
