Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Fox Factory Float 34
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 34 Float Factory, GRIP, 3-position, micro-adjust, 15mm x 110mm
Rear Shock
FOX Float DPX2 Factory EVOL, open(adjustable)/medium/firm mode, 185mm x 52.5mm, Trunnion 54mm upper mount, 22x8mm lower mount
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
Direct mount (none included)
Shift Levers
SRAM GX Eagle, trigger, 12-speed
Cassette
SRAM XG-1275, 10-50 tooth, 12-speed
Crank
SRAM X1 Carbon Eagle, 170mm
Bottom Bracket
Press-fit
Chain
SRAM GX Eagle
Chain Guide
None included
Pedals
None included
Wheels
Front Hub
Newmen Evolution SL A.25 wheelset, 15mm x 110mm front, 12mm x 148mm rear
Rear Hub
Newmen Evolution SL A.25 wheelset, 15mm x 110mm front, 12mm x 148mm rear
Rims
Newmen Evolution SL A.25 wheelset, 28 hole, tubeless ready
Spokes
Newmen Evolution SL A.25 wheelset
Tires
Front: Schwalbe Hans Dampf, Addix Soft, Tubeless Easy, kevlar, 27.5 x 2.35", Rear: Schwalbe Hans Dampf, Addix Speedgrip, Tubeless Easy, kevlar, 27.5 x 2.35"
Brakes
Brakes
SRAM Guide RSC with 180mm rotors (front and rear)
Brake Levers
SRAM Guide RSC
Cockpit
Stem
Newmen Evolution 318.4, 31.8mm diameter
Handlebar
Newmen Evolution 318.20, 760mm width
Grips
Cube Race SL 29.5, single clamp
Headset
FSA Orbit I-t, integrated
Seat
Saddle
Cube Natural Fit Active Race WS
Seatpost
FOX Transfer Factory, Kashima, 409mm x 125mm (100mm for 13.5" frame)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13.5" | 16" | 18" |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.37 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm |
| Front Center | 694 mm | 716 mm | 740 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 588 mm | 593 mm | 602 mm |
| Reach | 399 mm | 419 mm | 439 mm |
| Top Tube Length | 547.3 mm | 568.8 mm | 591.8 mm |
| Seat Tube Angle | 75.2 ° | 75.2 ° | 75.2 ° |
| Seat Tube Length | 350 mm | 370 mm | 420 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 102 mm | 107 mm | 117 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1120 mm | 1142 mm | 1166 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm |
| Wheels | 27" | 27" | 27" |
About this model
Sting 140 WS HPC SL completes the Cube Sting model. Cube launched 27 bikes of this model so far. You can easily view all of the Cube Sting bikes models from 2019, here.
Model range prices
CUBE STING WS 120 Exc 2019 is the cheapest bike model and costs 1485$. CUBE STING WS 140 HPC SL 27.5 2019 is the most expensive one and costs 3715$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 12.5 kg (27.56 lbs), the Sting 140 WS HPC SL model is slightly lighter than average. In other words, this model is 3.84% lighter than the average Trail bike.
Sting 140 WS HPC SL components
Fork
The fork installed on this bike is the Fox Factory Float 34 model. The travel on this model is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Sting 140 WS HPC SL has a rear shock with a travel of 140mm. The model FOX Float DPX2 Factory EVOL is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Sting 140 WS HPC SL bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
