Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork SunTour RAIDON
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HPA Ultralight, Advanced Hydroforming, Triple Butted, ETC 4-Link, AXH
Suspension Fork
Suntour Raidon XC LO-R, 120mm, 15x110mm, Tapered
Rear Shock
Suntour UNAir LOR8, 184x44mm
Drivetrain
Rear Derailleur
Shimano XT RD-M781-DSGSL, Shadow, 10-Speed
Front Derailleur
Shimano Deore FD-M617-D, Direct Mount, Side Swing
Shift Levers
Shimano Deore SL-M6000, Rapidfire-Plus
Cassette
Shimano CS-HG50, 11-36T
Crank
Shimano Deore FC-M617, 36x22T, 175mm
Chain
KMC X10
Wheels
Front Hub
Schimano Deore HB-M6010, Centerlock
Rear Hub
Schimano Deore FH-M6010, Centerlock
Rims
CUBE EX21, 32H, Disc
Tires
Schwalbe Tough Tom, Active, 2.25
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (180/180)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 700mm
Grips
CUBE Performance Grip
Seat
Saddle
CUBE WLS Active 1.1
Seatpost
CUBE Performance Post, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 16" | 17" | 19" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.41 mm | 1.46 mm | 1.43 mm |
| Stack | 580 mm | 584 mm | 616 mm | 626 mm |
| Reach | 395 mm | 414 mm | 422 mm | 438 mm |
| Top Tube Length | 549 mm | 569.5 mm | 579 mm | 598 mm |
| Seat Tube Angle | 74.74 ° | 74.74 ° | 75.23 ° | 75.23 ° |
| Seat Tube Length | 335 mm | 375 mm | 395 mm | 445 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 431 mm | 431 mm | 449 mm | 449 mm |
| Wheelbase | 1089 mm | 1110 mm | 1146 mm | 1166 mm |
| Rear Travel | 20 mm | 20 mm | 42 mm | 42 mm |
| Wheels | 27" | 27" | 27" | 27" |
About this model
STING WS 120 is part of the Cube Sting model. There are 27 bikes that carry this model name. Take a sneak peek at all Cube Sting bikes models from 2018, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
CUBE STING WS 120 it’s weighing 13.6 kg (29.98 lbs). At this weight, is a bit heavier than average. In other words, this model is 9.68% heavier than the average Crosscountry bike.
Overview of components
Fork
CUBE STING WS 120 2018 bike is equipped with the SunTour RAIDON fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Suntour UNAir LOR8 rear shock model, which has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The STING WS 120 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The STING WS 120 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
