Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset XT, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Trekking Comfort Double Butted
Suspension Fork
SR Suntour NEX HLO, 63mm
Drivetrain
Rear Derailleur
Shimano XT RD-M772, Shadow, 9-Speed
Front Derailleur
Shimano FD-T4000, Top-Swing, 31.8mm; EE: Shimano FD-T4000, Down-Swing, 34.9mm
Shift Levers
Shimano SL-M370, Rapidfire-Plus
Cassette
Shimano CS-HG200, 11-34T
Crank
Shimano FC-T3010, 48x36x26T, BB-UN100, 175mm
Chain
KMC X9
Pedals
Trekking Gummiert
Wheels
Front Hub
Shimano DH-3D37, Hub Dynamo, QR
Rear Hub
Shimano FH-M3050
Rims
CUBE ZX20, 36H, Disc
Tires
Schwalbe Spicer, Active, 40x622
Brakes
Brakes
Shimano BR-M315, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680mm; EE: CUBE Comfort Shape Bar
Grips
CUBE Natural Fit Comfort
Headset
FSA No.10, Semi-Integrated
Seat
Saddle
Selle Royal Freccia
Seatpost
CUBE Performance Post, 27.2mm; EE: CUBE Performance Post, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | 58cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.62 mm | 1.64 mm | 1.65 mm | 1.66 mm |
| Front Center | 618 mm | 625 mm | 634 mm | 650 | 665 mm |
| Rake | 42 mm | 42 mm | 42 mm | 41 mm | 41 mm |
| Trail | 82 mm | 79 mm | 76 mm | 77 mm | 77 mm |
| Stack | 584 mm | 605 mm | 626 mm | 645 mm | 663 mm |
| Reach | 369 mm | 374 mm | 381 mm | 391 mm | 400 mm |
| Top Tube Length | 550 mm | 561 mm | 575 mm | 590 mm | 605 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm | 580 mm | 620 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1048 mm | 1055 mm | 1064 mm | 1080 mm | 1095 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
TOURING Exc belongs to the Cube Touring model. There are 53 bikes that carry this model name. Take a sneak peek at all Cube Touring bikes models from 2017, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Hybrid bikes average weight
On a deeper look, we notice that the average weight of a Hybrid bike is 13.85 kg (30.53 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
much heavier than average, TOURING Exc has a weight of 16.4 kg (36.16 lbs). In conclusion, the average Hybrid bike weighs 18.41% less than TOURING Exc.
Overview of components
Fork
The TOURING Exc comes factory-installed with the SunTour NEX fork. This has a travel range of 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The TOURING Exc 2017 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE TOURING Exc is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
