Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset Deore, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Trekking Sport 29 Taper Double Butted
Suspension Fork
Aluminium Rigid Fork 29" Tapered
Drivetrain
Rear Derailleur
Shimano Deore RD-M592, 9-Speed
Front Derailleur
Shimano FD-M370, Topswing, 31.8mm
Shift Levers
Shimano SL-M370, Rapidfire-Plus
Cassette
Shimano CS-HG200, 11-34T
Crank
Shimano FC-M371, 48x36x26T, BB-UN100, 175mm, Chainguard
Chain
KMC X9
Pedals
Trekking Gummiert
Wheels
Front Hub
Shimano DH-3D32, Hub Dynamo, QR
Rear Hub
CUBE K68R
Rims
CUBE EX21, 32H, Disc, Tubeless Ready
Tires
Schwalbe Smart Sam, Active, 29x2.25"
Brakes
Brakes
Tektro HD-M285, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680mm
Grips
CUBE Performance Grip
Headset
FSA Orbit 1.5B ZS-1, Semi-Integrated, Top 1 1/8" Bottom 1 1/2"
Seat
Saddle
Selle Royal Viper
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.54 mm | 1.59 mm |
| Front Center | 638 mm | 638 mm | 638 mm |
| Rake | 45 mm | 45 mm | 46 mm |
| Trail | 81 mm | 74 mm | 67 mm |
| Stack | 590 mm | 613 mm | 636 mm |
| Reach | 395 mm | 397 mm | 399 mm |
| Top Tube Length | 557 mm | 571 mm | 586 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1105 mm | 1105 mm | 1105 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
TRAVEL is a Cube Travel model. CUBE launched 56 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Touring bikes
If you want an acceptable Touring bike you should know that the average price is 1007$. However, this doesn’t mean that if you spend less money on a Touring bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Touring bikes
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
CUBE TRAVEL it’s weighing 15.45 kg (34.06 lbs). At this weight, is much heavier than average. To sum up, it’s 15.73% heavier than the average weight of Touring bikes.
TRAVEL components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the TRAVEL model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. CUBE TRAVEL has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
