Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset Deore, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Trekking Sport 29 Taper Double Butted
Suspension Fork
Aluminium Rigid Fork 29" Tapered
Drivetrain
Rear Derailleur
Shimano Deore RD-M592, 9-Speed
Front Derailleur
Shimano FD-M370, Topswing, 31.8mm
Shift Levers
Shimano SL-M2000, Rapidfire-Plus
Cassette
Shimano CS-HG200, 11-34T
Crank
Shimano FC-T3010, 48x36x26T, 175mm, BB-UN100, Chainguard
Chain
KMC X9
Pedals
Trekking Gummiert
Wheels
Front Hub
Shimano DH-3D32, Hub Dynamo, QR
Rear Hub
CUBE Alloy Light
Rims
CUBE EX21, 32H, Disc, Tubeless Ready
Tires
Schwalbe Big Apple, Performance, 29x2.15
Brakes
Brakes
Tektro HD-M285, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680mm
Grips
CUBE Performance Grip
Headset
FSA Orbit 1.5B ZS-1, Semi-Integrated, Top 1 1/8" Bottom 1 1/2"
Seat
Saddle
Selle Royal Ariel
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | 58cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.51 mm | 1.56 mm | 1.6 mm | 1.64 mm |
| Front Center | 637 mm | 637 mm | 637 mm | 647 mm | 658 mm |
| Rake | 44 mm | 44 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82 mm | 75 mm | 68 mm | 68 mm | 68 mm |
| Stack | 581 mm | 604 mm | 627 mm | 646 mm | 669 mm |
| Reach | 398 mm | 400 mm | 402 mm | 405 mm | 408 mm |
| Top Tube Length | 557 mm | 571 mm | 586 mm | 601 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1104 mm | 1104 mm | 1104 mm | 1114 mm | 1125 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
TRAVEL is a Cube Travel model. CUBE launched 56 bikes of this model so far. Take a sneak peek at all Cube Travel bikes models from 2018, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Touring bikes
According to our math, the average price for a trustworthy Touring bike is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Touring bikes
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 15.6 kg (34.39 lbs), the TRAVEL model is much heavier than average. To sum up, it’s 16.85% heavier than the average weight of Touring bikes.
Overview of components
Fork material
TRAVEL has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The wheels on TRAVEL are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The TRAVEL comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
