Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset Rival eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
48cm
149cm - 157cm
50cm
154cm - 162cm
52cm
160cm - 168cm
53cm
166cm - 173cm
54cm
170cm - 176cm
55cm
173cm - 180cm
56cm
178cm - 185cm
58cm
183cm - 190cm
61cm
188cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titanium Curve Belgie V3
Suspension Fork
Curve Race 370
Drivetrain
Rear Derailleur
Rival eTap AXS D1 12sp (Max 36t)
Front Derailleur
Rival eTap AXS D1 Braze On
Shift Levers
Rival AXS eTap LH rear / RH front brake
Cassette
XG 1250 D1 XPLR 10-36t 12sp
Crank
Rival D1 DUB - 48/35, 48-50 cm: 165bmm 52-55 cm: 170 mm 56-61bcm: 175bmm
Bottom Bracket
Curve T47 DUB 68mm
Chain
Rival D1 12sp
Wheels
Tires
Rubino Pro TLR 700 x 30c
Brakes
Brakes
Rival D1 HRD Flat Mount Disc // CL Rotors 160mm
Cockpit
Handlebar
Zipp SC SL Beyond Black
Headset
Curve Integrated 42/52cmm semi-internal
Seat
Saddle
Fi'zi:k Vento Argo
Seatpost
Zipp SC SL - Zero Setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 53cm | 54cm | 55cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.407 mm | 1.393 mm | 1.394 mm | 1.383 mm | 1.384 mm | 1.379 mm | 1.377 mm | 1.424 mm | 1.487 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 264 mm | 264 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 564 mm | 570 mm | 571 mm | 582 mm | 591 mm | 602 mm | 612 mm | 623 mm | 642 mm |
| Rake | 43 mm | 44 mm | 43 mm | 44 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 67 mm | 63 mm | 61 mm | 60 mm | 61 mm | 61 mm | 61 mm | 58 mm | 58 mm |
| Stack | 515 mm | 521 mm | 527 mm | 534 mm | 544 mm | 553 mm | 562 mm | 591 mm | 629 mm |
| Reach | 366 mm | 374 mm | 378 mm | 386 mm | 393 mm | 401 mm | 408 mm | 415 mm | 423 mm |
| Top Tube Length | 515 mm | 525 mm | 535 mm | 545 mm | 555 mm | 565 mm | 575 mm | 595 mm | 615 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 485 mm | 505 mm | 525 mm | 535 mm | 545 mm | 555 mm | 570 mm | 590 mm | 625 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 130 mm | 140 mm | 150 mm | 160 mm | 190 mm | 230 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 412 mm | 412 mm | 412 mm | 415 mm | 415 mm |
| Wheelbase | 962 mm | 968 mm | 969 mm | 981 mm | 993 mm | 1003 mm | 1013 mm | 1028 mm | 1048 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 72 mm | 72 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 154 cm | 160 cm | 166 cm | 170 cm | 173 cm | 178 cm | 183 cm | 188 cm |
| Rider Max Height | 157 cm | 162 cm | 168 cm | 173 cm | 176 cm | 180 cm | 185 cm | 190 cm | 196 cm |
Model Overview
Belgie DISC completes the Curve Belgie model. Curve released 22 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Curve Belgie V3 2021 is the most economical model, with a starting price of 4752$. Curve Belgie DISC 2021 on the other hand costs 5789$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2021 for 5789$. If we compare this with the average Race bike cost we notice that the price is 72.81% more expensive.
Belgie DISC components
Wheels
As for the wheels, Curve Belgie DISC 2021, has a 700c model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Curve Belgie DISC bike has 9 sizes, in the range of 149 cm – 196 cm (4.89 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
